Honda Ridgeline I 3.5 i V6 24V (247 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Honda Ridgeline I 3.5 i V6 24V (247 Hp) /Pick-up 2005 - 2009/

What is the body type of Honda Ridgeline I?

Pick-up, 4 Doors, 5 Seats

What is the fuel consumption and economy of Honda Ridgeline I 3.5 i V6 24V (247 Hp)?

17 l/100 km
13.8 US mpg
16.6 UK mpg
5.9 km/l

How environmentally friendly is Honda Ridgeline 3.5 i V6 24V (247 Hp)?

Euro 4

What is the power output of Honda Ridgeline Pick-up 2005 3.5 i V6 24V (247 Hp)?

247 Hp, 339 Nm
250 lb.-ft.

What is the engine displacement of Honda Ridgeline Pick-up 2005 3.5 i V6 24V (247 Hp)?

3.5 l
3471 cm³
211.81 cu. in.

What is the number of cylinders in 2005 Honda 3.5 i V6 24V (247 Hp)?

6, V-engine

What is the drivetrain of Honda Ridgeline I Pick-up 2005 3.5 i V6 24V (247 Hp)?

All wheel drive (4x4). Internal Combustion engine.

What is the length of 2005 Honda Ridgeline Pick-up?

5253 mm
206.81 in.

What is the width of 2005 Honda Ridgeline Pick-up?

1976 mm
77.8 in.

What is the kerb weight of 2005 Honda Ridgeline I 3.5 i V6 24V (247 Hp)?

2041 kg
4500 lbs.

What are the number of gears and the gearbox type of 2005 Honda Ridgeline I 3.5 i V6 24V (247 Hp)?

5, automatic transmission

Honda
- Honda Ridgeline
  - Ridgeline I
    - 3.5 i V6 24V (247 Hp)

Compare

General information

Brand

Honda

Model

Ridgeline

Generation

Ridgeline I

Modification (Engine)

3.5 i V6 24V (247 Hp)

Start of production

2005

End of production

2009

Powertrain Architecture

Internal Combustion engine

Body type

Pick-up

Seats

Doors

Looking for Honda Ridgeline on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

20 l/100 km 11.8 US mpg
14.1 UK mpg
5 km/l

Fuel consumption (economy) - extra urban

15 l/100 km 15.7 US mpg
18.8 UK mpg
6.7 km/l

Fuel consumption (economy) - combined

17 l/100 km 13.8 US mpg
16.6 UK mpg
5.9 km/l

Fuel Type

Petrol (Gasoline)

Emission standard

Euro 4

Weight-to-power ratio

8.3 kg/Hp, 121 Hp/tonne

Weight-to-torque ratio

6 kg/Nm, 166.1 Nm/tonne

Engine specs

Power

247 Hp @ 6300 rpm.

Power per litre

71.2 Hp/l

Torque

339 Nm @ 4500 rpm. 250 lb.-ft. @ 4500 rpm.

Engine layout

Front, Transverse

Engine Model/Code

J35A9

Engine displacement

3471 cm³ 211.81 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

89 mm 3.5 in.

Piston Stroke

93 mm 3.66 in.

Compression ratio

10:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

4.3 l 4.54 US qt | 3.78 UK qt

Engine oil specification

Coolant

6.2 l 6.55 US qt | 5.46 UK qt

Volume and weights

Kerb Weight

2041 kg 4500 lbs.

Fuel tank capacity

100 l 26.42 US gal | 22 UK gal

Dimensions

Length

5253 mm 206.81 in.

Width

1976 mm 77.8 in.

Height

1786 mm 70.31 in.

Wheelbase

3100 mm 122.05 in.

Front track

1704 mm 67.09 in.

Rear (Back) track

1700 mm 66.93 in.

Drivetrain, brakes and suspension specs

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

5 gears, automatic transmission

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Tire size

245/65 R17

Specs of Honda Ridgeline I 3.5 i V6 24V (247 Hp) /2005, 2006, 2007, 2008, 2009/
