Honda Odyssey III 2.4 i 16V (160 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Honda Odyssey III 2.4 i 16V (160 Hp) /Minivan 2004 - 2010/

What is the body type of Honda Odyssey III?

Minivan, 5 Doors, 7 Seats

What is the fuel consumption and economy of Honda Odyssey III 2.4 i 16V (160 Hp)?

8.2 l/100 km
28.7 US mpg
34.4 UK mpg
12.2 km/l

How fast is 2004 Odyssey III 2.4 i 16V (160 Hp)?

180 km/h | 112 mph

What is the power output of Honda Odyssey Minivan 2004 2.4 i 16V (160 Hp)?

160 Hp, 218 Nm
161 lb.-ft.

What is the engine displacement of Honda Odyssey Minivan 2004 2.4 i 16V (160 Hp)?

2.4 l
2354 cm³
143.65 cu. in.

What is the number of cylinders in 2004 Honda 2.4 i 16V (160 Hp)?

4, Inline

What is the drivetrain of Honda Odyssey III Minivan 2004 2.4 i 16V (160 Hp)?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2004 Honda Odyssey Minivan?

4770 mm
187.8 in.

What is the width of 2004 Honda Odyssey Minivan?

1800 mm
70.87 in.

What is the kerb weight of 2004 Honda Odyssey III 2.4 i 16V (160 Hp)?

1600 kg
3527 lbs.

What is the maximum permissible mass of 2004 Honda Odyssey III 2.4 i 16V (160 Hp)?

2800 kg
6173 lbs.

What is the trunk (boot) capacity of 2004 Honda Odyssey Minivan?

280 - 1235 l
9.9 - 43.6 cu. ft.

What is the number of gears in What is the gearbox type of 2004 Honda Odyssey III 2.4 i 16V (160 Hp)?

5, manual transmission

Honda
- Honda Odyssey
  - Odyssey III
    - 2.4 i 16V 4WD (160 Hp)
    - 2.4 i 16V (160 Hp)

Compare

General information

Brand

Honda

Model

Odyssey

Generation

Odyssey III

Modification (Engine)

2.4 i 16V (160 Hp)

Start of production

2004 year

End of production

2010 year

Powertrain Architecture

Internal Combustion engine

Body type

Minivan

Seats

Doors

Performance specs

Fuel consumption (economy) - combined

8.2 l/100 km 28.7 US mpg
34.4 UK mpg
12.2 km/l

Fuel Type

Petrol (Gasoline)

Maximum speed

180 km/h 112 mph

Weight-to-power ratio

10 kg/Hp, 100 Hp/tonne

Weight-to-torque ratio

7.3 kg/Nm, 136.3 Nm/tonne

Engine specs

Power

160 Hp @ 5500 rpm.

Power per litre

68 Hp/l

Torque

218 Nm @ 4500 rpm. 161 lb.-ft. @ 4500 rpm.

Engine layout

Front, Transverse

Engine Model/Code

K24

Engine displacement

2354 cm³ 143.65 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

87 mm 3.43 in.

Piston Stroke

99 mm 3.9 in.

Compression ratio

9.7:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

4.2 l 4.44 US qt | 3.7 UK qt

Engine oil specification

Volume and weights

Kerb Weight

1600 kg 3527 lbs.

Max. weight

2800 kg 6173 lbs.

Max load

1200 kg 2646 lbs.

Trunk (boot) space - minimum

280 l 9.9 cu. ft.

Trunk (boot) space - maximum

1235 l 43.6 cu. ft.

Fuel tank capacity

65 l 17.17 US gal | 14.3 UK gal

Dimensions

Length

4770 mm 187.8 in.

Width

1800 mm 70.87 in.

Height

1550 mm 61.02 in.

Wheelbase

2830 mm 111.42 in.

Front track

1560 mm 61.42 in.

Rear (Back) track

1555 mm 61.22 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Wishbone

Rear suspension

Anti-roll bar

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Tires size

215/60 R16

Wheel rims size

6J x 16

Specs of Honda Odyssey III 2.4 i 16V (160 Hp) /2004, 2005, 2006, 2007, 2008, 2009, 2010/
