Honda Integra III (DC2) 1.6 ZXi (120 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Honda Integra III (DC2) 1.6 ZXi (120 Hp) /Liftback 1994 - 2001/

What is the body type of Honda Integra III (DC2)?

Liftback, 2 Doors, 4 Seats

What is the fuel consumption and economy of Honda Integra III (DC2) 1.6 ZXi (120 Hp)?

5.5 l/100 km
42.8 US mpg
51.4 UK mpg
18.2 km/l

How fast is 1994 Integra III (DC2) 1.6 ZXi (120 Hp)?

175 km/h | 109 mph

What is the power output of Honda Integra Liftback 1994 1.6 ZXi (120 Hp)?

120 Hp, 142 Nm
105 lb.-ft.

What is the engine displacement of Honda Integra Liftback 1994 1.6 ZXi (120 Hp)?

1.6 l
1590 cm³
97.03 cu. in.

What is the number of cylinders in 1994 Honda 1.6 ZXi (120 Hp)?

4, Inline

What is the drivetrain of Honda Integra III (DC2) Liftback 1994 1.6 ZXi (120 Hp)?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 1994 Honda Integra Liftback?

4380 mm
172.44 in.

What is the width of 1994 Honda Integra Liftback?

1695 mm
66.73 in.

What is the kerb weight of 1994 Honda Integra III (DC2) 1.6 ZXi (120 Hp)?

1050 kg
2315 lbs.

What are the number of gears and the gearbox type of 1994 Honda Integra III (DC2) 1.6 ZXi (120 Hp)?

5, manual transmission

Honda
- Honda Integra
  - Integra III (DC2)
    - 1.8i (142 Hp)
    - 1.8 i (180 Hp)
    - 1.6 ZXi (120 Hp)

Compare

General information

Brand

Honda

Model

Integra

Generation

Integra III (DC2)

Modification (Engine)

1.6 ZXi (120 Hp)

Start of production

1994

End of production

2001

Powertrain Architecture

Internal Combustion engine

Body type

Liftback

Seats

Doors

Looking for Honda Integra on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - combined

5.5 l/100 km 42.8 US mpg
51.4 UK mpg
18.2 km/l

Fuel Type

Petrol (Gasoline)

Maximum speed

175 km/h 109 mph

Weight-to-power ratio

8.8 kg/Hp, 114.3 Hp/tonne

Weight-to-torque ratio

7.4 kg/Nm, 135.2 Nm/tonne

Engine specs

Power

120 Hp @ 6300 rpm.

Power per litre

75.5 Hp/l

Torque

142 Nm @ 5500 rpm. 105 lb.-ft. @ 5500 rpm.

Engine layout

Front, Transverse

Engine displacement

1590 cm³ 97.03 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

75 mm 2.95 in.

Piston Stroke

90 mm 3.54 in.

Compression ratio

9.1:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

OHC

Engine oil specification

Volume and weights

Kerb Weight

1050 kg 2315 lbs.

Fuel tank capacity

50 l 13.21 US gal | 11 UK gal

Dimensions

Length

4380 mm 172.44 in.

Width

1695 mm 66.73 in.

Height

1335 mm 52.56 in.

Wheelbase

2570 mm 101.18 in.

Front track

1475 mm 58.07 in.

Rear (Back) track

1465 mm 57.68 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Coil spring

Rear suspension

Coil spring

Front brakes

Ventilated discs

Rear brakes

Drum

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Hydraulic Steering

Tire size

185/65 R14

Wheel rim size

Specs of Honda Integra III (DC2) 1.6 ZXi (120 Hp) /1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001/
