Honda Clarity 25.5 kWh (163 Hp) Electric Automatic | Technical specs, data, battery, electric range, Dimensions

Key specs

Honda Clarity 25.5 kWh (163 Hp) Electric Automatic /Sedan 2016 - 2019/

What is the body type of Honda Clarity?

Sedan, 4 Doors, 5 Seats

What is the all-electric range of 25.5 kWh (163 Hp) Electric Automatic?

143 km
89 mi

What is the power output of Honda Clarity Sedan 2016 25.5 kWh (163 Hp) Electric Automatic?

163 Hp

What is the drivetrain of Honda Clarity Sedan 2016 25.5 kWh (163 Hp) Electric Automatic?

Front wheel drive. BEV (Electric Vehicle). One electric motor drives the front wheels.

What is the length of 2016 Honda Clarity Sedan?

4895 mm
192.72 in.

What is the width of 2016 Honda Clarity Sedan?

1877 mm
73.9 in.

What is the kerb weight of 2016 Honda Clarity 25.5 kWh (163 Hp) Electric Automatic?

1825 kg
4023 lbs.

What is the trunk (boot) capacity of 2016 Honda Clarity Sedan?

405 l
14.3 cu. ft.

What are the number of gears and the gearbox type of 2016 Honda Clarity 25.5 kWh (163 Hp) Electric Automatic?

1, automatic transmission SBW

Honda
- Honda Clarity
  - Clarity
    - 25.5 kWh (163 Hp) Electric Automatic
    - 1.5 (212 Hp) Plug-in Hybrid e-CVT
    - (174 Hp) Fuel Cell Automatic

Compare

General information

Brand

Honda

Model

Clarity

Generation

Clarity

Modification (Engine)

25.5 kWh (163 Hp) Electric Automatic

Start of production

2016

End of production

2019

Powertrain Architecture

BEV (Electric Vehicle)

Body type

Sedan

Seats

Doors

Looking for Honda Clarity on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Weight-to-power ratio

11.2 kg/Hp, 89.3 Hp/tonne

Electric and hybrid car specs

Gross battery capacity

25.5 kWh

Electric range

143 km 89 mi

Electric motor 1

Electric motor power

163 Hp @ 4000-9500 rpm.

Electric motor Torque

300 Nm @ 0-3500 rpm. 221 lb.-ft. @ 0-3500 rpm.

System power

163 Hp @ 4000-9500 rpm.

Volume and weights

Kerb Weight

1825 kg 4023 lbs.

Trunk (boot) space - minimum

405 l 14.3 cu. ft.

Dimensions

Length

4895 mm 192.72 in.

Width

1877 mm 73.9 in.

Height

1478 mm 58.19 in.

Wheelbase

2751 mm 108.31 in.

Front track

1580 mm 62.2 in.

Rear (Back) track

1587 mm 62.48 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the front wheels.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

1 gears, automatic transmission SBW

Front suspension

Independent, McPherson type

Rear suspension

Independent multi-link suspension

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

235/45 R18

Wheel rim size

8J x 18

Specs of Honda Clarity 25.5 kWh (163 Hp) Electric Automatic /2016, 2017, 2018, 2019/
