GMC Terrain III 1.5L Turbo (177 Hp) CVT | Technical specs, data, fuel consumption, Dimensions

Key specs

GMC Terrain III 1.5L Turbo (177 Hp) CVT /SUV 2024 - /

What is the body type of GMC Terrain III?

SUV, 5 Doors, 5 Seats

What is the power output of GMC Terrain SUV 2024 1.5L Turbo (177 Hp) CVT?

177 Hp, 250 Nm
184 lb.-ft.

What is the engine displacement of GMC Terrain SUV 2024 1.5L Turbo (177 Hp) CVT?

1.5 l
1490 cm³
90.93 cu. in.

What is the number of cylinders in 2024 GMC 1.5L Turbo (177 Hp) CVT?

4, Inline

What is the drivetrain of GMC Terrain III SUV 2024 1.5L Turbo (177 Hp) CVT?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2024 GMC Terrain SUV?

4597 mm
180.98 in.

What is the width of 2024 GMC Terrain SUV?

1892 mm
74.49 in.

What is the kerb weight of 2024 GMC Terrain III 1.5L Turbo (177 Hp) CVT?

1563 kg
3446 lbs.

What is the trunk (boot) capacity of 2024 GMC Terrain SUV?

844 - 1799 l
29.8 - 63.5 cu. ft.

What is the number of gears in What is the gearbox type of 2024 GMC Terrain III 1.5L Turbo (177 Hp) CVT?

automatic transmission CVT

GMC
- GMC Terrain
  - Terrain III
    - 1.5L Turbo (177 Hp) CVT
    - 1.5L Turbo (177 Hp) AWD Automatic

Compare

General information

Brand

GMC

Model

Terrain

Generation

Terrain III

Modification (Engine)

1.5L Turbo (177 Hp) CVT

Start of production

August, 2024 year

Powertrain Architecture

Internal Combustion engine

Body type

SUV

Seats

Doors

Looking for GMC Terrain on the used-car market?

Check its history →

Performance specs

Fuel Type

Petrol (Gasoline)

Weight-to-power ratio

8.8 kg/Hp, 113.2 Hp/tonne

Weight-to-torque ratio

6.3 kg/Nm, 159.9 Nm/tonne

Engine specs

Power

177 Hp @ 5600 rpm.

Power per litre

118.8 Hp/l

Torque

250 Nm @ 2000-4800 rpm. 184 lb.-ft. @ 2000-4800 rpm.

Engine layout

Front, Transverse

Engine Model/Code

LYX

Engine displacement

1490 cm³ 90.93 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

74 mm 2.91 in.

Piston Stroke

86.6 mm 3.41 in.

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Turbocharger, Intercooler

Valvetrain

DOHC

Engine oil capacity

5 l 5.28 US qt | 4.4 UK qt

Engine oil specification

Coolant

6.6 l 6.97 US qt | 5.81 UK qt

Engine systems

Start & Stop System

Volume and weights

Kerb Weight

1563 kg 3446 lbs.

Trunk (boot) space - minimum

844 l 29.8 cu. ft.

Trunk (boot) space - maximum

1799 l 63.5 cu. ft.

Permitted trailer load with brakes (12%)

363 kg 800 lbs.

Dimensions

Length

4597 mm 180.98 in.

Width

1892 mm 74.49 in.

Height

1680 mm 66.14 in.

Wheelbase

2730 mm 107.48 in.

Front track

1626 mm 64.02 in.

Rear (Back) track

1628 mm 64.09 in.

Ride height (ground clearance)

205 mm 8.07 in.

Minimum turning circle (turning diameter)

11.3 m 37.07 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

automatic transmission CVT

Front suspension

Independent, McPherson type

Rear suspension

Independent multi-link suspension

Front brakes

Ventilated discs, 300x26 mm

Rear brakes

Disc, 288x12 mm

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

235/65 R17; 235/55 R19

Wheel rims size

17; 19
