GMC Hummer EV Pickup 170 kWh (830 Hp) e4WD | Technical Specs, Battery, Electric range, Dimensions

Key specs

GMC Hummer EV Pickup 170 kWh (830 Hp) e4WD /Pick-up, Targa 2022 - /

What is the body type of GMC Hummer EV Pickup?

Pick-up, Targa, 4 Doors, 5 Seats

What is the all-electric range of 170 kWh (830 Hp) e4WD?

480-505 km
298 - 314 mi

How fast is 2022 Hummer EV Pickup 170 kWh (830 Hp) e4WD?

170 km/h | 106 mph
0-60 mph: 3.5 sec

What is the power output of GMC Hummer EV Pick-up, Targa 2022 170 kWh (830 Hp) e4WD?

830 Hp

What is the drivetrain of GMC Hummer EV Pickup Pick-up, Targa 2022 170 kWh (830 Hp) e4WD?

All wheel drive (4x4). BEV. Two electric motors drive the rear wheels, one electric motor drives the front wheels.

What is the length of 2022 GMC Hummer EV Pick-up, Targa?

5507 mm
216.81 in.

What is the width of 2022 GMC Hummer EV Pick-up, Targa?

2201 mm
86.65 in.

What is the trunk (boot) capacity of 2022 GMC Hummer EV Pick-up, Targa?

1039 l
36.7 cu. ft.

What are the number of gears and the gearbox type of 2022 GMC Hummer EV Pickup 170 kWh (830 Hp) e4WD?

1, automatic transmission

GMC Hummer EV Pickup 170 kWh (830 Hp) e4WD

GMC
- GMC Hummer EV
  - Hummer EV Pickup
    - 246.8 kWh (1000 Hp) e4WD
    - 170 kWh (830 Hp) e4WD
    - 170 kWh (625 Hp) e4WD
    - 170 kWh (570 Hp) e4WD

Compare

General information

Brand

GMC

Model

Hummer EV

Generation

Hummer EV Pickup

Modification (Engine)

170 kWh (830 Hp) e4WD

Start of production

2022

Powertrain Architecture

BEV (Electric Vehicle)

Body type

Pick-up, Targa

Seats

Doors

Looking for GMC Hummer EV on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Acceleration 0 - 60 mph

3.5 sec

Maximum speed

170 km/h 106 mph

Electric and hybrid car specs

Gross battery capacity

170 kWh

Battery voltage

800 V

Battery technology

Lithium nickel cobalt manganese aluminum (Li-NCMA)

Battery location

Below the floor

Electric range (EPA)

480-505 km 298 - 314 mi

Charging ports

Charging times

Electric motor 1

Electric motor location

Rear axle, Transverse

Electric motor type

Synchronous

Electric motor 2

Electric motor location

Rear axle, Transverse

Electric motor type

Synchronous

Electric motor 3

Electric motor location

Front axle, Transverse

Electric motor type

Synchronous

System power

830 Hp

Volume and weights

Trunk (boot) space - maximum

1039 l 36.7 cu. ft.

Permitted trailer load with brakes (12%)

3856 kg 8501 lbs.

Dimensions

Length

5507 mm 216.81 in.

Width

2201 mm 86.65 in.

Width with mirrors folded

2223 mm 87.52 in.

Width including mirrors

2380 mm 93.7 in.

Height

2009 mm 79.09 in.

Wheelbase

3445 mm 135.63 in.

Front track

1863 mm 73.35 in.

Rear (Back) track

1863 mm 73.35 in.

Front overhang

881 mm 34.69 in.

Rear overhang

1181 mm 46.5 in.

Ride height (ground clearance)

257-404 mm 10.12 - 15.91 in.

Minimum turning circle (turning diameter)

11.3 m 37.07 ft.

Approach angle

41.5-49.7°

Departure angle

31.6-38.4°

Ramp-over (breakover) angle

22.3-32.2°

Wading depth

660-813 mm 25.98 - 32.01 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

Two electric motors drive the rear wheels, one electric motor drives the front wheels.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Double wishbone, Air suspension

Rear suspension

Double wishbone, Air suspension

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)
4-wheel steering (4WS, active rear steering)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

305/70 R18; 305/55 R22

Wheel rim size

9J x 18; 9.5J x 22
