Forthing V9 1.5TD (310 Hp) Plug-in Hybrid DHT | Technical specs, data, fuel consumption, Dimensions

Key specs

Forthing V9 1.5TD (310 Hp) Plug-in Hybrid DHT /Minivan, MPV 2024 - /

What is the body type of Forthing V9?

Minivan, MPV, 5 Doors, 7 Seats

What is the fuel consumption and economy of Forthing V9 1.5TD (310 Hp) Plug-in Hybrid DHT?

1.7-6.1 l/100 km
138.4 - 38.6 US mpg
166.2 - 46.3 UK mpg
58.8 - 16.4 km/l

How environmentally friendly is Forthing V9 1.5TD (310 Hp) Plug-in Hybrid DHT?

40-141 g/km CO₂

What is the all-electric range of 1.5TD (310 Hp) Plug-in Hybrid DHT?

90-120 km
56 - 75 mi

What is the electricity consumption of Forthing V9 1.5TD (310 Hp) Plug-in Hybrid DHT?

20-26 kWh/100 km
32.19 - 41.84 kWh/100 mi
105 - 81 MPGe
5 - 3.8 km/kWh
3.1 - 2.4 mi/kWh

How fast is 2024 V9 1.5TD (310 Hp) Plug-in Hybrid DHT?

180 km/h | 112 mph
0-100 km/h: 9.5 sec
0-60 mph: 9 sec

What is the power output of Forthing V9 Minivan, MPV 2024 1.5TD (310 Hp) Plug-in Hybrid DHT?

310 Hp

What is the engine displacement of Forthing V9 Minivan, MPV 2024 1.5TD (310 Hp) Plug-in Hybrid DHT?

1.5 l
1497 cm³
91.35 cu. in.

What is the number of cylinders in 2024 Forthing 1.5TD (310 Hp) Plug-in Hybrid DHT?

4, Inline

What is the drivetrain of Forthing V9 Minivan, MPV 2024 1.5TD (310 Hp) Plug-in Hybrid DHT?

Front wheel drive. PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode.

What is the length of 2024 Forthing V9 Minivan, MPV?

5251 mm
206.73 in.

What is the width of 2024 Forthing V9 Minivan, MPV?

1920 mm
75.59 in.

What is the kerb weight of 2024 Forthing V9 1.5TD (310 Hp) Plug-in Hybrid DHT?

2205-2415 kg
4861 - 5324 lbs.

What is the maximum permissible mass of 2024 Forthing V9 1.5TD (310 Hp) Plug-in Hybrid DHT?

2850-2940 kg
6283 - 6482 lbs.

What is the trunk (boot) capacity of 2024 Forthing V9 Minivan, MPV?

593 - 2792 l
20.9 - 98.6 cu. ft.

What is the number of gears in What is the gearbox type of 2024 Forthing V9 1.5TD (310 Hp) Plug-in Hybrid DHT?

1, automatic transmission DHT

Forthing
- Forthing V9
  - V9
    - 1.5TD (177 Hp) HEV E-CVT
    - 1.5TD (310 Hp) Plug-in Hybrid DHT

Compare

General information

Brand

Forthing

Model

Generation

Modification (Engine)

1.5TD (310 Hp) Plug-in Hybrid DHT

Start of production

June, 2024 year

Powertrain Architecture

PHEV (Plug-in Hybrid Electric Vehicle)

Body type

Minivan, MPV

Seats

Doors

Looking for Forthing V9 on the used-car market?

Check its history →

Performance specs

Combined fuel consumption (WLTP)

1.7-6.1 l/100 km 138.4 - 38.6 US mpg
166.2 - 46.3 UK mpg
58.8 - 16.4 km/l

CO₂ emissions (WLTP)

40-141 g/km

Fuel consumption (economy) - combined (WLTC)

1.2-6.2 l/100 km 196 - 37.9 US mpg
235.4 - 45.6 UK mpg
83.3 - 16.1 km/l

Fuel Type

Petrol / electricity

Acceleration 0 - 100 km/h

9.5 sec

Acceleration 0 - 62 mph

9.5 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

9 sec

Maximum speed

180 km/h 112 mph

Weight-to-power ratio

7.1 kg/Hp, 140.6 Hp/tonne

Electric cars and hybrids specs

Gross battery capacity

34.9 kWh

Battery voltage

336 V

Battery technology

Lithium iron phosphate (LiFePO₄)

Electric range (WLTP)

90-120 km 56 - 75 mi

Electric range

160-200 km 99 - 124 mi

Average Energy consumption (WLTP)

20-26 kWh/100 km 32.19 - 41.84 kWh/100 mi
105 - 81 MPGe
5 - 3.8 km/kWh
3.1 - 2.4 mi/kWh

Average Energy consumption

21.9 kWh/100 km 35.24 kWh/100 mi
96 MPGe
4.6 km/kWh
2.8 mi/kWh

Charging ports

Electric motor 1

Electric motor power

204 Hp

Electric motor Torque

310 Nm 229 lb.-ft.

Electric motor model/code

TZ236XY150

Electric motor location

Integrated into the transmission

Electric motor type

Synchronous

System power

310 Hp

Internal combustion engine specs

Power

154 Hp @ 5200 rpm.

Power per litre

102.9 Hp/l

Engine layout

Front, Transverse

Engine Model/Code

DFMC15TE3

Engine displacement

1497 cm³ 91.35 cu. in.

Number of cylinders

Engine configuration

Inline

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Turbocharger, Intercooler

Valvetrain

DOHC

Engine systems

Start & Stop System

Volume and weights

Kerb Weight

2205-2415 kg 4861 - 5324 lbs.

Max. weight

2850-2940 kg 6283 - 6482 lbs.

Max load

525-645 kg 1157 - 1422 lbs.

Trunk (boot) space - minimum

593 l 20.9 cu. ft.

Trunk (boot) space - maximum

2792 l 98.6 cu. ft.

Fuel tank capacity

58 l 15.32 US gal | 12.76 UK gal

Dimensions

Length

5251 mm 206.73 in.

Width

1920 mm 75.59 in.

Height

1810-1820 mm 71.26 - 71.65 in.

Wheelbase

3018 mm 118.82 in.

Front track

1633 mm 64.29 in.

Rear (Back) track

1646 mm 64.8 in.

Minimum turning circle (turning diameter)

12.3 m 40.35 ft.

Approach angle

13°

Departure angle

16°

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

1 gears, automatic transmission DHT

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Independent multi-link spring suspension with anti-roll bar

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

225/55 R18; 245/45 R19

Wheel rims size

18; 19

Specs of Forthing V9 1.5TD (310 Hp) Plug-in Hybrid DHT /2024, 2025, 2026/
