Ford Mustang Mach-E GT 98.7 kWh (487 Hp) AWD | Technical specs, data, battery, electric range, Dimensions

Key specs

Ford Mustang Mach-E GT 98.7 kWh (487 Hp) AWD /Coupe, SUV 2020 - 2021/

What is the body type of Ford Mustang Mach-E?

Coupe, SUV, 5 Doors, 5 Seats

What is the all-electric range of GT 98.7 kWh (487 Hp) AWD?

500 km
311 mi

What is the electricity consumption of Ford Mustang Mach-E GT 98.7 kWh (487 Hp) AWD?

20 kWh/100 km
32.19 kWh/100 mi
105 MPGe
5 km/kWh
3.1 mi/kWh

How fast is 2020 Mustang Mach-E GT 98.7 kWh (487 Hp) AWD?

200 km/h | 124 mph
0-100 km/h: 4.4 sec
0-60 mph: 4.2 sec

What is the power output of Ford Mustang Mach-E Coupe, SUV 2020 GT 98.7 kWh (487 Hp) AWD?

487 Hp, 830 Nm
612 lb.-ft.

What is the drivetrain of Ford Mustang Mach-E Coupe, SUV 2020 GT 98.7 kWh (487 Hp) AWD?

All wheel drive (4x4). BEV (Electric Vehicle). One electric motor drives the front wheels, one electric motor drives the rear wheels.

What is the length of 2020 Ford Mustang Mach-E Coupe, SUV?

4743 mm
186.73 in.

What is the width of 2020 Ford Mustang Mach-E Coupe, SUV?

1881 mm
74.06 in.

What is the kerb weight of 2020 Ford Mustang Mach-E GT 98.7 kWh (487 Hp) AWD?

2273 kg
5011 lbs.

What is the maximum permissible mass of 2020 Ford Mustang Mach-E GT 98.7 kWh (487 Hp) AWD?

2717 kg
5990 lbs.

What is the trunk (boot) capacity of 2020 Ford Mustang Mach-E Coupe, SUV?

402 - 1420 l
14.2 - 50.1 cu. ft.

What are the number of gears and the gearbox type of 2020 Ford Mustang Mach-E GT 98.7 kWh (487 Hp) AWD?

1, automatic transmission

Compare

General information

Brand

Ford

Model

Mustang Mach-E

Generation

Mustang Mach-E

Modification (Engine)

GT 98.7 kWh (487 Hp) AWD

Start of production

2020

End of production

December, 2021

Powertrain Architecture

BEV (Electric Vehicle)

Body type

Coupe, SUV

Seats

Doors

Looking for Ford Mustang Mach-E on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Acceleration 0 - 100 km/h

4.4 sec

Acceleration 0 - 62 mph

4.4 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

4.2 sec

Maximum speed

200 km/h 124 mph

Weight-to-power ratio

4.7 kg/Hp, 214.3 Hp/tonne

Weight-to-torque ratio

2.7 kg/Nm, 365.2 Nm/tonne

Electric and hybrid car specs

Gross battery capacity

98.7 kWh

Net (usable) battery capacity

88 kWh

Battery technology

Lithium nickel manganese cobalt oxides (Li-NMC)

Battery location

Below the floor

Electric range (WLTP)

500 km 311 mi

Average Energy consumption (WLTP)

20 kWh/100 km 32.19 kWh/100 mi
105 MPGe
5 km/kWh
3.1 mi/kWh

Charging ports

Charging times

Electric motor 1

Electric motor location

Rear axle, Transverse

Electric motor 2

Electric motor location

Front axle, Transverse

System power

487 Hp

System torque

830 Nm 612 lb.-ft.

Volume and weights

Kerb Weight

2273 kg 5011 lbs.

Max. weight

2717 kg 5990 lbs.

Max load

444 kg 979 lbs.

Trunk (boot) space - minimum

402 l 14.2 cu. ft.

Trunk (boot) space - maximum

1420 l 50.1 cu. ft.

Permitted trailer load with brakes (12%)

750 kg 1653 lbs.

Permitted trailer load without brakes

750 kg 1653 lbs.

Permitted towbar download

30 kg 66 lbs.

Dimensions

Length

4743 mm 186.73 in.

Width

1881 mm 74.06 in.

Width with mirrors folded

1930 mm 75.98 in.

Width including mirrors

2097 mm 82.56 in.

Height

1613 mm 63.5 in.

Wheelbase

2984 mm 117.48 in.

Front track

1622 mm 63.86 in.

Rear (Back) track

1630 mm 64.17 in.

Ride height (ground clearance)

130 mm 5.12 in.

Minimum turning circle (turning diameter)

11.6 m 38.06 ft.

Approach angle

14.4°

Departure angle

24.2°

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the front wheels, one electric motor drives the rear wheels.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Independent, McPherson type, Anti-roll bar

Rear suspension

Independent multi-link suspension, Anti-roll bar

Front brakes

Ventilated discs, 385x27 mm

Rear brakes

Disc, 316x11 mm

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

245/45 R20

Wheel rim size

8J x 20
