Ford Falcon (FG) XR8 5.4 V8 (394 Hp) Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

Ford Falcon (FG) XR8 5.4 V8 (394 Hp) Automatic /Sedan 2008 - 2010/

What is the body type of Ford Falcon (FG)?

Sedan, 4 Doors, 5 Seats

What is the fuel consumption and economy of Ford Falcon (FG) XR8 5.4 V8 (394 Hp) Automatic?

14 l/100 km
16.8 US mpg
20.2 UK mpg
7.1 km/l

What is the power output of Ford Falcon Sedan 2008 XR8 5.4 V8 (394 Hp) Automatic?

394 Hp, 520 Nm
384 lb.-ft.

What is the engine displacement of Ford Falcon Sedan 2008 XR8 5.4 V8 (394 Hp) Automatic?

5.4 l
5408 cm³
330.02 cu. in.

What is the number of cylinders in 2008 Ford XR8 5.4 V8 (394 Hp) Automatic?

8, V-engine

What is the drivetrain of Ford Falcon (FG) Sedan 2008 XR8 5.4 V8 (394 Hp) Automatic?

Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

What is the length of 2008 Ford Falcon Sedan?

4970 mm
195.67 in.

What is the width of 2008 Ford Falcon Sedan?

1868 mm
73.54 in.

What is the trunk (boot) capacity of 2008 Ford Falcon Sedan?

535 l
18.9 cu. ft.

What are the number of gears and the gearbox type of 2008 Ford Falcon (FG) XR8 5.4 V8 (394 Hp) Automatic?

6, automatic transmission

Ford
- Ford Falcon
  - Falcon (FG)
    - XR8 5.4 V8 (394 Hp) Automatic
    - 4.0 E-Gas (212 Hp) Automatic
    - 4.0 DI-VCT Turbo (367 Hp) Automatic
    - 4.0 DI-VCT Turbo (367 Hp)
    - 4.0 DI-VCT (265 Hp) 6 Automatic
    - 4.0 DI-VCT (265 Hp) 5 Automatic
    - 4.0 DI-VCT (265 Hp)

Compare

General information

Brand

Ford

Model

Falcon

Generation

Falcon (FG)

Modification (Engine)

XR8 5.4 V8 (394 Hp) Automatic

Start of production

2008

End of production

2010

Powertrain Architecture

Internal Combustion engine

Body type

Sedan

Seats

Doors

Looking for Ford Falcon on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

21.4 l/100 km 11 US mpg
13.2 UK mpg
4.7 km/l

Fuel consumption (economy) - extra urban

9.7 l/100 km 24.2 US mpg
29.1 UK mpg
10.3 km/l

Fuel consumption (economy) - combined

14 l/100 km 16.8 US mpg
20.2 UK mpg
7.1 km/l

Fuel Type

Petrol (Gasoline)

Engine specs

Power

394 Hp @ 5750 rpm.

Power per litre

72.9 Hp/l

Torque

520 Nm @ 4750 rpm. 384 lb.-ft. @ 4750 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

Boss 290

Engine displacement

5408 cm³ 330.02 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

90.2 mm 3.55 in.

Piston Stroke

105.8 mm 4.17 in.

Compression ratio

10.5:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Volume and weights

Trunk (boot) space - minimum

535 l 18.9 cu. ft.

Fuel tank capacity

68 l 17.96 US gal | 14.96 UK gal

Permitted trailer load with brakes (12%)

2300 kg 5071 lbs.

Dimensions

Length

4970 mm 195.67 in.

Width

1868 mm 73.54 in.

Width including mirrors

2100 mm 82.68 in.

Height

1433 mm 56.42 in.

Wheelbase

2838 mm 111.73 in.

Front track

1583 mm 62.32 in.

Rear (Back) track

1598 mm 62.91 in.

Front overhang

954 mm 37.56 in.

Rear overhang

1179 mm 46.42 in.

Minimum turning circle (turning diameter)

11 m 36.09 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

6 gears, automatic transmission

Front suspension

Double wishbone

Rear suspension

Independent multi-link suspension

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Hydraulic Steering

Tire size

245/45 R17; 245/40 R18; 245/35 R19

Wheel rim size

8J x 17; 8J x 18; 8J x 19
