Ford Explorer EV 82 kWh (340 Hp) Extended Range AWD | Technical specs, data, battery, electric range, Dimensions

Key specs

Ford Explorer EV 82 kWh (340 Hp) Extended Range AWD /SUV 2024 - /

What is the body type of Ford Explorer EV?

SUV, 5 Doors, 5 Seats

What is the all-electric range of 82 kWh (340 Hp) Extended Range AWD?

532-566 km
331 - 352 mi

What is the electricity consumption of Ford Explorer EV 82 kWh (340 Hp) Extended Range AWD?

15.7-16.6 kWh/100 km
25.27 - 26.72 kWh/100 mi
133 - 126 MPGe
6.4 - 6 km/kWh
4 - 3.7 mi/kWh

How fast is 2024 Explorer EV 82 kWh (340 Hp) Extended Range AWD?

180 km/h | 112 mph
0-100 km/h: 5.3 sec
0-60 mph: 5 sec

What is the power output of Ford Explorer EV SUV 2024 82 kWh (340 Hp) Extended Range AWD?

340 Hp, 679 Nm
501 lb.-ft.

What is the drivetrain of Ford Explorer EV SUV 2024 82 kWh (340 Hp) Extended Range AWD?

All wheel drive (4x4). BEV (Electric Vehicle). One electric motor drives the front wheels, one electric motor drives the rear wheels.

What is the length of 2024 Ford Explorer EV SUV?

4468 mm
175.91 in.

What is the width of 2024 Ford Explorer EV SUV?

1871 mm
73.66 in.

What is the kerb weight of 2024 Ford Explorer EV 82 kWh (340 Hp) Extended Range AWD?

2092-2104 kg
4612 - 4639 lbs.

What is the maximum permissible mass of 2024 Ford Explorer EV 82 kWh (340 Hp) Extended Range AWD?

2740 kg
6041 lbs.

What is the trunk (boot) capacity of 2024 Ford Explorer EV SUV?

440 - 1422 l
15.5 - 50.2 cu. ft.

What is the number of gears in What is the gearbox type of 2024 Ford Explorer EV 82 kWh (340 Hp) Extended Range AWD?

1, automatic transmission

Ford
- Ford Explorer EV
  - Explorer EV
    - 82 kWh (340 Hp) Extended Range AWD
    - 82 kWh (286 Hp) Extended Range RWD
    - 58 kWh (190 Hp) Standard Range RWD
    - 52 kWh (170 Hp) Standard Range RWD

Compare

General information

Brand

Ford

Model

Explorer EV

Generation

Explorer EV

Modification (Engine)

82 kWh (340 Hp) Extended Range AWD

Start of production

March, 2024 year

Powertrain Architecture

BEV (Electric Vehicle)

Body type

SUV

Seats

Doors

Looking for Ford Explorer EV on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Acceleration 0 - 100 km/h

5.3 sec

Acceleration 0 - 62 mph

5.3 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

5 sec

Maximum speed

180 km/h 112 mph

Weight-to-power ratio

6.2 kg/Hp, 162.5 Hp/tonne

Weight-to-torque ratio

3.1 kg/Nm, 324.6 Nm/tonne

Electric cars and hybrids specs

Gross battery capacity

82 kWh

Net (usable) battery capacity

79 kWh

Battery technology

Lithium nickel manganese cobalt oxides (Li-NMC)

Battery location

Below the floor

Electric range (WLTP)

532-566 km 331 - 352 mi

Average Energy consumption (WLTP)

15.7-16.6 kWh/100 km 25.27 - 26.72 kWh/100 mi
133 - 126 MPGe
6.4 - 6 km/kWh
4 - 3.7 mi/kWh

Charging ports

Electric motor 1

Electric motor Torque

545 Nm 402 lb.-ft.

Electric motor location

Rear axle, Transverse

Electric motor type

Synchronous

Electric motor 2

Electric motor Torque

134 Nm 99 lb.-ft.

Electric motor location

Front axle, Transverse

Electric motor type

Asynchronous

System power

340 Hp

System torque

679 Nm 501 lb.-ft.

Volume and weights

Kerb Weight

2092-2104 kg 4612 - 4639 lbs.

Max. weight

2740 kg 6041 lbs.

Max load

636-648 kg 1402 - 1429 lbs.

Trunk (boot) space - minimum

440 l 15.5 cu. ft.

Trunk (boot) space - maximum

1422 l 50.2 cu. ft.

Max. roof load

75 kg 165 lbs.

Permitted trailer load with brakes (12%)

1200 kg 2646 lbs.

Permitted trailer load without brakes

750 kg 1653 lbs.

Permitted towbar download

75 kg 165 lbs.

Dimensions

Length

4468 mm 175.91 in.

Width

1871 mm 73.66 in.

Width with mirrors folded

1946 mm 76.61 in.

Width including mirrors

2063 mm 81.22 in.

Height

1639 mm 64.53 in.

Wheelbase

2767 mm 108.94 in.

Front track

1587 mm 62.48 in.

Rear (Back) track

1572 mm 61.89 in.

Front overhang

851 mm 33.5 in.

Rear overhang

850 mm 33.46 in.

Ride height (ground clearance)

148 mm 5.83 in.

Minimum turning circle (turning diameter)

11 m 36.09 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the front wheels, one electric motor drives the rear wheels.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

1 gears, automatic transmission

Front brakes

Ventilated discs

Rear brakes

Drum

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

Front wheel tires: 235/55 R19; 235/50 R20; 235/45 R21
Rear wheel tires: 255/50 R19; 255/45 R20; 255/40 R21

Wheel rims size

Front wheel rims: 8.0J x 19; 8.0J x 20; 8.5J x 21
Rear wheel rims: 8.5J x 19; 9.0J x 20; 9.0J x 21

Specs of Ford Explorer EV 82 kWh (340 Hp) Extended Range AWD /2024, 2025, 2026/
