Ford Expedition I (U173) 5.4 i V8 16V XLT 4WD (232 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Ford Expedition I (U173) 5.4 i V8 16V XLT 4WD (232 Hp) /SUV 1996 - 2003/

What is the body type of Ford Expedition I (U173)?

SUV, 5 Doors, 5 Seats

How fast is 1996 Expedition I (U173) 5.4 i V8 16V XLT 4WD (232 Hp)?

180 km/h | 112 mph
0-100 km/h: 10 sec
0-60 mph: 9.5 sec

What is the power output of Ford Expedition SUV 1996 5.4 i V8 16V XLT 4WD (232 Hp)?

232 Hp, 441 Nm
325 lb.-ft.

What is the engine displacement of Ford Expedition SUV 1996 5.4 i V8 16V XLT 4WD (232 Hp)?

5.4 l
5398 cm³
329.41 cu. in.

What is the number of cylinders in 1996 Ford 5.4 i V8 16V XLT 4WD (232 Hp)?

8, V-engine

What is the drivetrain of Ford Expedition I (U173) SUV 1996 5.4 i V8 16V XLT 4WD (232 Hp)?

All wheel drive (4x4). Internal Combustion engine.

What is the length of 1996 Ford Expedition SUV?

5200 mm
204.72 in.

What is the width of 1996 Ford Expedition SUV?

2000 mm
78.74 in.

What is the kerb weight of 1996 Ford Expedition I (U173) 5.4 i V8 16V XLT 4WD (232 Hp)?

2360 kg
5203 lbs.

What is the trunk (boot) capacity of 1996 Ford Expedition SUV?

3350 l
118.3 cu. ft.

What are the number of gears and the gearbox type of 1996 Ford Expedition I (U173) 5.4 i V8 16V XLT 4WD (232 Hp)?

4, automatic transmission

Ford
- Ford Expedition
  - Expedition I (U173)
    - 5.4 i V8 16V (264 Hp) 4WD
    - 5.4 i V8 16V (264 Hp)
    - 5.4 i V8 16V XLT 4WD (232 Hp)
    - 5.4 i V8 16V XLT (232 Hp)
    - 4.6 i V8 16V XLT 4WD (243 Hp)
    - 4.6 i V8 16V XLT (243 Hp)
    - 4.6 i V8 16V XLT (218 Hp)

Compare

General information

Brand

Ford

Model

Expedition

Generation

Expedition I (U173)

Modification (Engine)

5.4 i V8 16V XLT 4WD (232 Hp)

Start of production

1996

End of production

2003

Powertrain Architecture

Internal Combustion engine

Body type

SUV

Seats

Doors

Looking for Ford Expedition on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

18.1 l/100 km 13 US mpg
15.6 UK mpg
5.5 km/l

Fuel consumption (economy) - extra urban

13.1 l/100 km 18 US mpg
21.6 UK mpg
7.6 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

10 sec

Acceleration 0 - 62 mph

10 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

9.5 sec

Maximum speed

180 km/h 112 mph

Weight-to-power ratio

10.2 kg/Hp, 98.3 Hp/tonne

Weight-to-torque ratio

5.4 kg/Nm, 186.9 Nm/tonne

Engine specs

Power

232 Hp @ 4250 rpm.

Power per litre

43 Hp/l

Torque

441 Nm @ 3000 rpm. 325 lb.-ft. @ 3000 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

Triton

Engine displacement

5398 cm³ 329.41 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

90.2 mm 3.55 in.

Piston Stroke

105.7 mm 4.16 in.

Compression ratio

9:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

OHC

Engine oil capacity

5.7 l 6.02 US qt | 5.02 UK qt

Engine oil specification

Coolant

19.7 l 20.82 US qt | 17.33 UK qt

Volume and weights

Kerb Weight

2360 kg 5203 lbs.

Trunk (boot) space - maximum

3350 l 118.3 cu. ft.

Fuel tank capacity

98 l 25.89 US gal | 21.56 UK gal

Dimensions

Length

5200 mm 204.72 in.

Width

2000 mm 78.74 in.

Height

1900 mm 74.8 in.

Wheelbase

3020 mm 118.9 in.

Front track

1660 mm 65.35 in.

Rear (Back) track

1660 mm 65.35 in.

Drivetrain, brakes and suspension specs

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

4 gears, automatic transmission

Front suspension

Torsion bar

Rear suspension

Rigid axle suspension

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Power steering

Hydraulic Steering

Tire size

265/70 R17

Specs of Ford Expedition I (U173) 5.4 i V8 16V XLT 4WD (232 Hp) /1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003/
