Ford C-MAX II 1.6 Duratec Ti-VCT (105 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Ford C-MAX II 1.6 Duratec Ti-VCT (105 Hp) /MPV 2010 - 2014/

What is the body type of Ford C-MAX II?

MPV, 5 Doors, 5 Seats

What is the fuel consumption and economy of Ford C-MAX II 1.6 Duratec Ti-VCT (105 Hp)?

6.6 l/100 km
35.6 US mpg
42.8 UK mpg
15.2 km/l

How environmentally friendly is Ford C-MAX 1.6 Duratec Ti-VCT (105 Hp)?

154 g/km CO₂
Euro 5

How fast is 2010 C-MAX II 1.6 Duratec Ti-VCT (105 Hp)?

180 km/h | 112 mph
0-100 km/h: 12.6 sec
0-60 mph: 12 sec

What is the power output of Ford C-MAX MPV 2010 1.6 Duratec Ti-VCT (105 Hp)?

105 Hp, 150 Nm
111 lb.-ft.

What is the engine displacement of Ford C-MAX MPV 2010 1.6 Duratec Ti-VCT (105 Hp)?

1.6 l
1596 cm³
97.39 cu. in.

What is the number of cylinders in 2010 Ford 1.6 Duratec Ti-VCT (105 Hp)?

4, Inline

What is the drivetrain of Ford C-MAX II MPV 2010 1.6 Duratec Ti-VCT (105 Hp)?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2010 Ford C-MAX MPV?

4380 mm
172.44 in.

What is the width of 2010 Ford C-MAX MPV?

1828 mm
71.97 in.

What is the kerb weight of 2010 Ford C-MAX II 1.6 Duratec Ti-VCT (105 Hp)?

1374 kg
3029 lbs.

What is the maximum permissible mass of 2010 Ford C-MAX II 1.6 Duratec Ti-VCT (105 Hp)?

1860 kg
4101 lbs.

What is the trunk (boot) capacity of 2010 Ford C-MAX MPV?

432 - 1723 l
15.3 - 60.8 cu. ft.

What are the number of gears and the gearbox type of 2010 Ford C-MAX II 1.6 Duratec Ti-VCT (105 Hp)?

5, manual transmission

Ford
- Ford C-MAX
  - C-MAX II

Compare

General information

Brand

Ford

Model

C-MAX

Generation

C-MAX II

Modification (Engine)

1.6 Duratec Ti-VCT (105 Hp)

Start of production

2010

End of production

2014

Powertrain Architecture

Internal Combustion engine

Body type

MPV

Seats

Doors

Looking for Ford C-MAX on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

8.7 l/100 km 27 US mpg
32.5 UK mpg
11.5 km/l

Fuel consumption (economy) - extra urban

5.3 l/100 km 44.4 US mpg
53.3 UK mpg
18.9 km/l

Fuel consumption (economy) - combined

6.6 l/100 km 35.6 US mpg
42.8 UK mpg
15.2 km/l

CO₂ emissions

154 g/km

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

12.6 sec

Acceleration 0 - 62 mph

12.6 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

12 sec

Maximum speed

180 km/h 112 mph

Emission standard

Euro 5

Weight-to-power ratio

13.1 kg/Hp, 76.4 Hp/tonne

Weight-to-torque ratio

9.2 kg/Nm, 109.2 Nm/tonne

Engine specs

Power

105 Hp @ 6000 rpm.

Power per litre

65.8 Hp/l

Torque

150 Nm @ 4000-4500 rpm. 111 lb.-ft. @ 4000-4500 rpm.

Engine layout

Front, Transverse

Engine Model/Code

IQDB

Engine displacement

1596 cm³ 97.39 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

79 mm 3.11 in.

Piston Stroke

81.4 mm 3.2 in.

Compression ratio

11:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

4.1 l 4.33 US qt | 3.61 UK qt

Engine oil specification

Coolant

5.8 l 6.13 US qt | 5.1 UK qt

Volume and weights

Kerb Weight

1374 kg 3029 lbs.

Max. weight

1860 kg 4101 lbs.

Max load

486 kg 1071 lbs.

Trunk (boot) space - minimum

432 l 15.3 cu. ft.

Trunk (boot) space - maximum

1723 l 60.8 cu. ft.

Fuel tank capacity

55 l 14.53 US gal | 12.1 UK gal

Max. roof load

75 kg 165 lbs.

Permitted towbar download

75 kg 165 lbs.

Dimensions

Length

4380 mm 172.44 in.

Width

1828 mm 71.97 in.

Width with mirrors folded

1858 mm 73.15 in.

Width including mirrors

2067 mm 81.38 in.

Height

1626 mm 64.02 in.

Wheelbase

2648 mm 104.25 in.

Front track

1544-1559 mm 60.79 - 61.38 in.

Rear (Back) track

1554-1569 mm 61.18 - 61.77 in.

Minimum turning circle (turning diameter)

10.7 m 35.1 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Independent multi-link spring suspension with anti-roll bar

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

205/55 R16; 215/55 R16

Wheel rim size

6.5 J x 16; 7.0 J x 16

Specs of Ford C-MAX II 1.6 Duratec Ti-VCT (105 Hp) /2010, 2011, 2012, 2013, 2014/
