Fiat Idea 1.4 i 16V (95 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Fiat Idea 1.4 i 16V (95 Hp) /Minivan 2003 - 2010/

What is the body type of Fiat Idea?

Minivan, 5 Doors, 5 Seats

What is the fuel consumption and economy of Fiat Idea 1.4 i 16V (95 Hp)?

6.6 l/100 km
35.6 US mpg
42.8 UK mpg
15.2 km/l

How fast is 2003 Idea 1.4 i 16V (95 Hp)?

175 km/h | 109 mph
0-100 km/h: 11.5 sec
0-60 mph: 10.9 sec

What is the power output of Fiat Idea Minivan 2003 1.4 i 16V (95 Hp)?

95 Hp, 128 Nm
94 lb.-ft.

What is the engine displacement of Fiat Idea Minivan 2003 1.4 i 16V (95 Hp)?

1.4 l
1368 cm³
83.48 cu. in.

What is the number of cylinders in 2003 Fiat 1.4 i 16V (95 Hp)?

4, Inline

What is the drivetrain of Fiat Idea Minivan 2003 1.4 i 16V (95 Hp)?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2003 Fiat Idea Minivan?

3930 mm
154.72 in.

What is the width of 2003 Fiat Idea Minivan?

1700 mm
66.93 in.

What is the kerb weight of 2003 Fiat Idea 1.4 i 16V (95 Hp)?

1155 kg
2546 lbs.

What is the trunk (boot) capacity of 2003 Fiat Idea Minivan?

320 - 1420 l
11.3 - 50.1 cu. ft.

What are the number of gears and the gearbox type of 2003 Fiat Idea 1.4 i 16V (95 Hp)?

5, manual transmission

Fiat
- Fiat Idea
  - Idea
    - 1.9 JTD (101 Hp)
    - 1.4 i 16V (95 Hp)
    - 1.4 i 8V (77 Hp)
    - 1.3 JTD MultiJet (70 Hp)
    - 1.2 i 16V (80 Hp)
    - 1.2 16V Multijet (90 Hp)

Compare

General information

Brand

Fiat

Model

Idea

Generation

Idea

Modification (Engine)

1.4 i 16V (95 Hp)

Start of production

2003

End of production

2010

Powertrain Architecture

Internal Combustion engine

Body type

Minivan

Seats

Doors

Looking for Fiat Idea on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

8.5 l/100 km 27.7 US mpg
33.2 UK mpg
11.8 km/l

Fuel consumption (economy) - extra urban

5.5 l/100 km 42.8 US mpg
51.4 UK mpg
18.2 km/l

Fuel consumption (economy) - combined

6.6 l/100 km 35.6 US mpg
42.8 UK mpg
15.2 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

11.5 sec

Acceleration 0 - 62 mph

11.5 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

10.9 sec

Maximum speed

175 km/h 109 mph

Weight-to-power ratio

12.2 kg/Hp, 82.3 Hp/tonne

Weight-to-torque ratio

9 kg/Nm, 110.8 Nm/tonne

Engine specs

Power

95 Hp @ 5800 rpm.

Power per litre

69.4 Hp/l

Torque

128 Nm @ 4500 rpm. 94 lb.-ft. @ 4500 rpm.

Engine layout

Front, Transverse

Engine Model/Code

843A1000

Engine displacement

1368 cm³ 83.48 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

72 mm 2.83 in.

Piston Stroke

84 mm 3.31 in.

Compression ratio

11.2:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

2.9 l 3.06 US qt | 2.55 UK qt

Engine oil specification

Coolant

4.5 l 4.76 US qt | 3.96 UK qt

Volume and weights

Kerb Weight

1155 kg 2546 lbs.

Trunk (boot) space - minimum

320 l 11.3 cu. ft.

Trunk (boot) space - maximum

1420 l 50.1 cu. ft.

Fuel tank capacity

47 l 12.42 US gal | 10.34 UK gal

Dimensions

Length

3930 mm 154.72 in.

Width

1700 mm 66.93 in.

Height

1660 mm 65.35 in.

Wheelbase

2510 mm 98.82 in.

Front track

1435 mm 56.5 in.

Rear (Back) track

1425 mm 56.1 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Suspension strut

Rear suspension

Torsion bar

Front brakes

Disc

Rear brakes

Drum

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

195/60 R15

Wheel rim size

6J x 15

Specs of Fiat Idea 1.4 i 16V (95 Hp) /2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010/
