Ferrari F430 Spider 4.3 i V8 32V (490 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Ferrari F430 Spider 4.3 i V8 32V (490 Hp) /Cabriolet 2004 - 2009/

What is the body type of Ferrari F430 Spider?

Cabriolet, 2 Doors, 2 Seats

How fast is 2004 F430 Spider 4.3 i V8 32V (490 Hp)?

310 km/h | 193 mph
0-100 km/h: 4.1 sec
0-60 mph: 3.9 sec

What is the power output of Ferrari F430 Cabriolet 2004 4.3 i V8 32V (490 Hp)?

490 Hp, 465 Nm
343 lb.-ft.

What is the engine displacement of Ferrari F430 Cabriolet 2004 4.3 i V8 32V (490 Hp)?

4.3 l
4308 cm³
262.89 cu. in.

What is the number of cylinders in 2004 Ferrari 4.3 i V8 32V (490 Hp)?

8, V-engine

What is the drivetrain of Ferrari F430 Spider Cabriolet 2004 4.3 i V8 32V (490 Hp)?

Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

What is the length of 2004 Ferrari F430 Cabriolet?

4512 mm
177.64 in.

What is the width of 2004 Ferrari F430 Cabriolet?

1923 mm
75.71 in.

What is the kerb weight of 2004 Ferrari F430 Spider 4.3 i V8 32V (490 Hp)?

1520 kg
3351 lbs.

What is the maximum permissible mass of 2004 Ferrari F430 Spider 4.3 i V8 32V (490 Hp)?

1770 kg
3902 lbs.

What is the trunk (boot) capacity of 2004 Ferrari F430 Cabriolet?

250 l
8.8 cu. ft.

What are the number of gears and the gearbox type of 2004 Ferrari F430 Spider 4.3 i V8 32V (490 Hp)?

7, automatic transmission

Ferrari
- Ferrari F430
  - F430 Spider
    - 4.3 i V8 32V (510 Hp)
    - 4.3 i V8 32V (490 Hp)

Compare

General information

Brand

Ferrari

Model

F430

Generation

F430 Spider

Modification (Engine)

4.3 i V8 32V (490 Hp)

Start of production

2004

End of production

2009

Powertrain Architecture

Internal Combustion engine

Body type

Cabriolet

Seats

Doors

Looking for Ferrari F430 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

26.9 l/100 km 8.7 US mpg
10.5 UK mpg
3.7 km/l

Fuel consumption (economy) - extra urban

13.3 l/100 km 17.7 US mpg
21.2 UK mpg
7.5 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

4.1 sec

Acceleration 0 - 62 mph

4.1 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

3.9 sec

Maximum speed

310 km/h 193 mph

Weight-to-power ratio

3.1 kg/Hp, 322.4 Hp/tonne

Weight-to-torque ratio

3.3 kg/Nm, 305.9 Nm/tonne

Engine specs

Power

490 Hp @ 8500 rpm.

Power per litre

113.7 Hp/l

Torque

465 Nm @ 5250 rpm. 343 lb.-ft. @ 5250 rpm.

Engine layout

Middle, Longitudinal

Engine Model/Code

F136E

Engine displacement

4308 cm³ 262.89 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

92 mm 3.62 in.

Piston Stroke

81 mm 3.19 in.

Compression ratio

11.3:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Engine oil capacity

10 l 10.57 US qt | 8.8 UK qt

Engine oil specification

Coolant

17.5 l 18.49 US qt | 15.4 UK qt

Volume and weights

Kerb Weight

1520 kg 3351 lbs.

Max. weight

1770 kg 3902 lbs.

Max load

250 kg 551 lbs.

Trunk (boot) space - minimum

250 l 8.8 cu. ft.

Fuel tank capacity

95 l 25.1 US gal | 20.9 UK gal

Dimensions

Length

4512 mm 177.64 in.

Width

1923 mm 75.71 in.

Height

1234 mm 48.58 in.

Wheelbase

2600 mm 102.36 in.

Front track

1669 mm 65.71 in.

Rear (Back) track

1616 mm 63.62 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

7 gears, automatic transmission

Front suspension

Double wishbone

Rear suspension

Double wishbone

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Tire size

Front wheel tires: 225/35 ZR19
Rear wheel tires: 285/35 R19

Specs of Ferrari F430 Spider 4.3 i V8 32V (490 Hp) /2004, 2005, 2006, 2007, 2008, 2009/
