Ferrari 330 GTC 4.0 V12 (300 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Ferrari 330 GTC 4.0 V12 (300 Hp) /Coupe 1966 - 1968/

What is the body type of Ferrari 330 GTC?

Coupe, 2 Doors, 2 Seats

How fast is 1966 330 GTC 4.0 V12 (300 Hp)?

242 km/h | 150 mph

What is the power output of Ferrari 330 Coupe 1966 4.0 V12 (300 Hp)?

300 Hp

What is the engine displacement of Ferrari 330 Coupe 1966 4.0 V12 (300 Hp)?

4.0 l
3967 cm³
242.08 cu. in.

What is the number of cylinders in 1966 Ferrari 4.0 V12 (300 Hp)?

12, V-engine

What is the drivetrain of Ferrari 330 GTC Coupe 1966 4.0 V12 (300 Hp)?

Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

What is the length of 1966 Ferrari 330 Coupe?

4470 mm
175.98 in.

What is the width of 1966 Ferrari 330 Coupe?

1665 mm
65.55 in.

What is the kerb weight of 1966 Ferrari 330 GTC 4.0 V12 (300 Hp)?

1300 kg
2866 lbs.

What are the number of gears and the gearbox type of 1966 Ferrari 330 GTC 4.0 V12 (300 Hp)?

5, manual transmission

Ferrari
- Ferrari 330
  - 330 GTC
    - 4.0 V12 (300 Hp)

Compare

General information

Brand

Ferrari

Model

330

Generation

330 GTC

Modification (Engine)

4.0 V12 (300 Hp)

Start of production

1966

End of production

1968

Powertrain Architecture

Internal Combustion engine

Body type

Coupe

Seats

Doors

Looking for Ferrari 330 on the used-car market?

Check its history →

Performance specs

Fuel Type

Petrol (Gasoline)

Maximum speed

242 km/h 150 mph

Weight-to-power ratio

4.3 kg/Hp, 230.8 Hp/tonne

Engine specs

Power

300 Hp @ 7000 rpm.

Power per litre

75.6 Hp/l

Engine layout

Front, Longitudinal

Engine displacement

3967 cm³ 242.08 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

77 mm 3.03 in.

Piston Stroke

71 mm 2.8 in.

Compression ratio

8.8:1

Number of valves per cylinder

Fuel injection system

Carburettor

Engine aspiration

Naturally aspirated engine

Valvetrain

SOHC

Engine oil specification

Volume and weights

Kerb Weight

1300 kg 2866 lbs.

Fuel tank capacity

90 l 23.78 US gal | 19.8 UK gal

Dimensions

Length

4470 mm 175.98 in.

Width

1665 mm 65.55 in.

Height

1282 mm 50.47 in.

Wheelbase

2400 mm 94.49 in.

Front track

1401 mm 55.16 in.

Rear (Back) track

1417 mm 55.79 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Coil spring, Double wishbone, Anti-roll bar

Rear suspension

Double wishbone, Anti-roll bar, Coil spring

Front brakes

Disc

Rear brakes

Disc

Steering type

Worm-reduction unit

Tire size

205/80 R14

Wheel rim size

Specs of Ferrari 330 GTC 4.0 V12 (300 Hp) /1966, 1967, 1968/
