Fangchengbao Titanium 3 78.72 kWh (422 Hp) 4WD | Technical specs, data, battery, electric range, Dimensions

Key specs

Fangchengbao Titanium 3 78.72 kWh (422 Hp) 4WD /SUV, Crossover 2025 - /

What is the body type of Fangchengbao Titanium 3?

SUV, Crossover, 5 Doors, 5 Seats

What is the all-electric range of 78.72 kWh (422 Hp) 4WD?

501 km
311 mi

What is the electricity consumption of Fangchengbao Titanium 3 78.72 kWh (422 Hp) 4WD?

17.9 kWh/100 km
28.81 kWh/100 mi
117 MPGe
5.6 km/kWh
3.5 mi/kWh

How fast is 2025 Titanium 3 78.72 kWh (422 Hp) 4WD?

201 km/h | 125 mph
0-100 km/h: 5.3 sec
0-60 mph: 5 sec

What is the power output of Fangchengbao Titanium 3 SUV, Crossover 2025 78.72 kWh (422 Hp) 4WD?

422 Hp, 510 Nm
376 lb.-ft.

What is the drivetrain of Fangchengbao Titanium 3 SUV, Crossover 2025 78.72 kWh (422 Hp) 4WD?

All wheel drive (4x4). BEV (Electric Vehicle). One electric motor drives the front wheels, one electric motor drives the rear wheels.

What is the length of 2025 Fangchengbao Titanium 3 SUV, Crossover?

4605 mm
181.3 in.

What is the width of 2025 Fangchengbao Titanium 3 SUV, Crossover?

1900 mm
74.8 in.

What is the kerb weight of 2025 Fangchengbao Titanium 3 78.72 kWh (422 Hp) 4WD?

2265 kg
4993 lbs.

What is the maximum permissible mass of 2025 Fangchengbao Titanium 3 78.72 kWh (422 Hp) 4WD?

2640 kg
5820 lbs.

What are the number of gears and the gearbox type of 2025 Fangchengbao Titanium 3 78.72 kWh (422 Hp) 4WD?

1, automatic transmission

Fangchengbao
- Fangchengbao Titanium 3
  - Titanium 3
    - 78.72 kWh (422 Hp) 4WD
    - 72.96 kWh (422 Hp) 4WD
    - 65.28 kWh (218 Hp)

Compare

General information

Brand

Fangchengbao

Model

Titanium 3

Generation

Titanium 3

Modification (Engine)

78.72 kWh (422 Hp) 4WD

Start of production

April, 2025

Powertrain Architecture

BEV (Electric Vehicle)

Body type

SUV, Crossover

Seats

Doors

Looking for Fangchengbao Tai 3 on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Acceleration 0 - 100 km/h

5.3 sec

Acceleration 0 - 62 mph

5.3 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

5 sec

Maximum speed

201 km/h 125 mph

Weight-to-power ratio

5.4 kg/Hp, 186.3 Hp/tonne

Weight-to-torque ratio

4.4 kg/Nm, 225.2 Nm/tonne

Electric and hybrid car specs

Gross battery capacity

78.72 kWh

Battery voltage

800 V

Battery technology

Lithium iron phosphate (LiFePO₄)

Battery location

Below the floor

Electric range (CLTC)

501 km 311 mi

Average Energy consumption (CLTC)

17.9 kWh/100 km 28.81 kWh/100 mi
117 MPGe
5.6 km/kWh
3.5 mi/kWh

Charging ports

Electric motor 1

Electric motor power

272 Hp

Electric motor Torque

310 Nm 229 lb.-ft.

Electric motor model/code

TZ200XYZ

Maximum electric motor speed

20000 rpm.

Electric motor location

Rear axle, Transverse

Electric motor type

Synchronous

Electric motor 2

Electric motor power

150 Hp

Electric motor Torque

200 Nm 148 lb.-ft.

Electric motor model/code

YS230XYC

Electric motor location

Front axle, Transverse

Electric motor type

Asynchronous

System power

422 Hp

System torque

510 Nm 376 lb.-ft.

Volume and weights

Kerb Weight

2265 kg 4993 lbs.

Max. weight

2640 kg 5820 lbs.

Max load

375 kg 827 lbs.

Dimensions

Length

4605 mm 181.3 in.

Width

1900 mm 74.8 in.

Height

1930 mm 75.98 in.

Wheelbase

2745 mm 108.07 in.

Front track

1634 mm 64.33 in.

Rear (Back) track

1650 mm 64.96 in.

Approach angle

25°

Departure angle

28°

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the front wheels, one electric motor drives the rear wheels.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Independent multi-link spring suspension with anti-roll bar

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

245/50 R19

Wheel rim size

Specs of Fangchengbao Titanium 3 78.72 kWh (422 Hp) 4WD /2025, 2026/
