Dodge Viper ZB II - Technical Specs, Fuel consumption, Dimensions

Fuel consumption & economy, Dimensions, technical data
(2007-2010) Dodge Viper ZB II 8.4i V10 20V SRT-10 (600 Hp)

General information

BrandDodge
Model Viper
Generation Viper ZB II
Modification (Engine) 8.4i V10 20V SRT-10 (600 Hp)
Start of production 2007 year
End of production 2010 year
Body type Cabriolet
Seats 2
Doors 2

Performance specs

Fuel consumption (economy) - urban 30.5 l/100 km 7.71 US mpg
9.26 UK mpg
Fuel consumption (economy) - extra urban 12.4 l/100 km 18.97 US mpg
22.78 UK mpg
Fuel consumption (economy) - combined 19.4 l/100 km 12.12 US mpg
14.56 UK mpg
Fuel Type Petrol (Gasoline)
Acceleration 0 - 100 km/h 3.9 sec
0 - 60 mph (Calculated by Auto-Data.net) 3.7 sec
Maximum speed 325 km/h 201.95 mph

Engine specs

Power 600 hp @ 6100 rpm.
Torque 760 Nm @ 5000 rpm. 560.55 lb.-ft. @ 5000 rpm.
Engine location Front, Longitudinal
Engine displacement 8382 cm3 511.5 cu. in.
Number of cylinders 10
Position of cylinders V engine
Cylinder Bore 103 mm 4.06 in.
Piston Stroke 100.6 mm 3.96 in.
Compression ratio 10.2
Number of valves per cylinder 2
Fuel System Multi-point indirect injection
Valvetrain -

Space, Volume and weights

Kerb Weight 1560 kg 3439.21 lbs.
Max. weight 1800 kg 3968.32 lbs.
Trunk (boot) space - maximum 240 l 8.48 cu. ft.
Fuel tank capacity 70 l 18.49 US gal | 15.4 UK gal

Dimensions

Length 4459 mm 175.55 in.
Width 1911 mm 75.24 in.
Height 1210 mm 47.64 in.
Wheelbase 2510 mm 98.82 in.
Front track 1565 mm 61.61 in.
Rear (Back) track 1547 mm 60.91 in.

Drivetrain, brakes and suspension specs

Drive wheel Rear wheel drive
Number of Gears (manual transmission) 6
Front suspension Independent, Spring McPherson, with stabilizer
Rear suspension Independent, spring multi-link with stabilizer
Front brakesVentilated discs
Rear brakesDisc
ABS yes
Steering type Steering rack
Power steering Hydraulic Steering
Tires size 275/35 R19; 345/30 R19

FAQ

What is the body type?

Cabriolet, 2 Doors, 2 Seats

How much power?

600 hp, 760 Nm | 560.55 lb.-ft.

What is the drivetrain?

Rear wheel drive

What is the engine size?
How many cylinders?

10, V engine

How long is this vehicle?

4459 mm | 175.55 in.

How wide is the vehicle?

1911 mm | 75.24 in.

What is the curb weigh?

1560 kg | 3439.21 lbs.

What is the gross weigh?

1800 kg | 3968.32 lbs.

How much trunk (boot) space?

0 - 240 l | 0 - 8.48 cu. ft.

How many gears?

6

What type is the gearbox?
