Deepal S09 1.5T 40.18 kWh (492 Hp) 4WD Extended Range | Technical specs, data, fuel consumption, Dimensions

Key specs

Deepal S09 1.5T 40.18 kWh (492 Hp) 4WD Extended Range /SUV 2025 - /

What is the body type of Deepal S09?

SUV, 5 Doors, 6 Seats

What is the fuel consumption and economy of Deepal S09 1.5T 40.18 kWh (492 Hp) 4WD Extended Range?

0.91-6.9 l/100 km
258.5 - 34.1 US mpg
310.4 - 40.9 UK mpg
109.9 - 14.5 km/l

What is the all-electric range of 1.5T 40.18 kWh (492 Hp) 4WD Extended Range?

170-210 km
106 - 130 mi

What is the electricity consumption of Deepal S09 1.5T 40.18 kWh (492 Hp) 4WD Extended Range?

23.3 kWh/100 km
37.5 kWh/100 mi
90 MPGe
4.3 km/kWh
2.7 mi/kWh

How fast is 2025 S09 1.5T 40.18 kWh (492 Hp) 4WD Extended Range?

205 km/h | 127 mph
0-100 km/h: 5.9 sec
0-60 mph: 5.6 sec

What is the power output of Deepal S09 SUV 2025 1.5T 40.18 kWh (492 Hp) 4WD Extended Range?

492 Hp, 637 Nm
470 lb.-ft.

What is the engine displacement of Deepal S09 SUV 2025 1.5T 40.18 kWh (492 Hp) 4WD Extended Range?

1.5 l
1497 cm³
91.35 cu. in.

What is the number of cylinders in 2025 Deepal 1.5T 40.18 kWh (492 Hp) 4WD Extended Range?

4, Inline

What is the drivetrain of Deepal S09 SUV 2025 1.5T 40.18 kWh (492 Hp) 4WD Extended Range?

All wheel drive (4x4). PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) drives the generator only, with no mechanical connection to the drive. Two electric motors drive the front and rear wheels.

What is the length of 2025 Deepal S09 SUV?

5205 mm
204.92 in.

What is the width of 2025 Deepal S09 SUV?

1996 mm
78.58 in.

What is the kerb weight of 2025 Deepal S09 1.5T 40.18 kWh (492 Hp) 4WD Extended Range?

2668 kg
5882 lbs.

What is the maximum permissible mass of 2025 Deepal S09 1.5T 40.18 kWh (492 Hp) 4WD Extended Range?

3180 kg
7011 lbs.

What is the trunk (boot) capacity of 2025 Deepal S09 SUV?

427 - 1392 l
15.1 - 49.2 cu. ft.

What are the number of gears and the gearbox type of 2025 Deepal S09 1.5T 40.18 kWh (492 Hp) 4WD Extended Range?

1, automatic transmission

Deepal
- Deepal S09
  - S09
    - 1.5T 40.18 kWh (492 Hp) 4WD Extended Range
    - 1.5T 40.18 kWh (314 Hp) Extended Range

Compare

General information

Brand

Deepal

Model

S09

Generation

S09

Modification (Engine)

1.5T 40.18 kWh (492 Hp) 4WD Extended Range

Start of production

April, 2025

Powertrain Architecture

PHEV (Plug-in Hybrid Electric Vehicle)

Body type

SUV

Seats

Doors

Looking for Deepal S09 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - combined (WLTC)

0.91-6.9 l/100 km 258.5 - 34.1 US mpg
310.4 - 40.9 UK mpg
109.9 - 14.5 km/l

Fuel Type

Petrol / electricity

Acceleration 0 - 100 km/h

5.9 sec

Acceleration 0 - 62 mph

5.9 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

5.6 sec

Maximum speed

205 km/h 127 mph

Weight-to-power ratio

5.4 kg/Hp, 184.4 Hp/tonne

Weight-to-torque ratio

4.2 kg/Nm, 238.8 Nm/tonne

Electric and hybrid car specs

Gross battery capacity

40.18 kWh

Battery technology

Lithium iron phosphate (LiFePO₄)

Electric range

170-210 km 106 - 130 mi

Average Energy consumption

23.3 kWh/100 km 37.5 kWh/100 mi
90 MPGe
4.3 km/kWh
2.7 mi/kWh

Charging ports

Electric motor 1

Electric motor power

314 Hp

Electric motor Torque

375 Nm 277 lb.-ft.

Electric motor model/code

ATDM02

Electric motor location

Rear axle, Transverse

Electric motor type

Synchronous

Electric motor 2

Electric motor power

178 Hp

Electric motor Torque

262 Nm 193 lb.-ft.

Electric motor model/code

AYDM01

Electric motor location

Front axle, Transverse

Electric motor type

Asynchronous

System power

492 Hp

System torque

637 Nm 470 lb.-ft.

Internal combustion engine specs

Power

150 Hp @ 5000 rpm.

Power per litre

100.2 Hp/l

Torque

220 Nm @ 3200-4200 rpm. 162 lb.-ft. @ 3200-4200 rpm.

Engine layout

Front, Transverse

Engine Model/Code

JL469ZQ1

Engine displacement

1497 cm³ 91.35 cu. in.

Number of cylinders

Engine configuration

Inline

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Turbocharger, Intercooler

Valvetrain

DOHC

Volume and weights

Kerb Weight

2668 kg 5882 lbs.

Max. weight

3180 kg 7011 lbs.

Max load

512 kg 1129 lbs.

Trunk (boot) space - minimum

427 l 15.1 cu. ft.

Trunk (boot) space - maximum

1392 l 49.2 cu. ft.

Fuel tank capacity

50 l 13.21 US gal | 11 UK gal

Dimensions

Length

5205 mm 204.92 in.

Width

1996 mm 78.58 in.

Height

1800 mm 70.87 in.

Wheelbase

3105 mm 122.24 in.

Front track

1690 mm 66.54 in.

Rear (Back) track

1700 mm 66.93 in.

Drag coefficient (C_d)

0.283

Minimum turning circle (turning diameter)

11.6 m 38.06 ft.

Approach angle

19°

Departure angle

21°

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the generator only, with no mechanical connection to the drive. Two electric motors drive the front and rear wheels.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Double wishbone, Anti-roll bar, Air suspension

Rear suspension

Independent multi-link suspension, Air suspension, Anti-roll bar

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

255/50 R20; 265/45 R21

Wheel rim size

20; 21

Specs of Deepal S09 1.5T 40.18 kWh (492 Hp) 4WD Extended Range /2025, 2026/
