Daihatsu Sigra 1.2 (88 Hp) Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

Daihatsu Sigra 1.2 (88 Hp) Automatic /MPV 2016 - 2019/

What is the body type of Daihatsu Sigra?

MPV, 5 Doors, 7 Seats

What is the power output of Daihatsu Sigra MPV 2016 1.2 (88 Hp) Automatic?

88 Hp, 108 Nm
80 lb.-ft.

What is the engine displacement of Daihatsu Sigra MPV 2016 1.2 (88 Hp) Automatic?

1.2 l
1197 cm³
73.05 cu. in.

What is the number of cylinders in 2016 Daihatsu 1.2 (88 Hp) Automatic?

4, Inline

What is the drivetrain of Daihatsu Sigra MPV 2016 1.2 (88 Hp) Automatic?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2016 Daihatsu Sigra MPV?

4070 mm
160.24 in.

What is the width of 2016 Daihatsu Sigra MPV?

1655 mm
65.16 in.

What is the kerb weight of 2016 Daihatsu Sigra 1.2 (88 Hp) Automatic?

985-990 kg
2172 - 2183 lbs.

What is the maximum permissible mass of 2016 Daihatsu Sigra 1.2 (88 Hp) Automatic?

1500-1570 kg
3307 - 3461 lbs.

What are the number of gears and the gearbox type of 2016 Daihatsu Sigra 1.2 (88 Hp) Automatic?

4, automatic transmission

Daihatsu
- Daihatsu Sigra
  - Sigra
    - 1.2 (88 Hp) Automatic
    - 1.2 (88 Hp)
    - 1.0 (67 Hp)

Compare

General information

Brand

Daihatsu

Model

Sigra

Generation

Sigra

Modification (Engine)

1.2 (88 Hp) Automatic

Start of production

2016

End of production

2019

Powertrain Architecture

Internal Combustion engine

Body type

MPV

Seats

Doors

Looking for Daihatsu Sigra on the used-car market?

Check its history →

Performance specs

Fuel Type

Petrol (Gasoline)

Weight-to-power ratio

11.2 kg/Hp, 89.3 Hp/tonne

Weight-to-torque ratio

9.1 kg/Nm, 109.6 Nm/tonne

Engine specs

Power

88 Hp @ 6000 rpm.

Power per litre

73.5 Hp/l

Torque

108 Nm @ 4200 rpm. 80 lb.-ft. @ 4200 rpm.

Engine layout

Front, Transverse

Engine Model/Code

3NR-VE

Engine displacement

1197 cm³ 73.05 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

72.5 mm 2.85 in.

Piston Stroke

72.5 mm 2.85 in.

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC, D-VVT-i

Volume and weights

Kerb Weight

985-990 kg 2172 - 2183 lbs.

Max. weight

1500-1570 kg 3307 - 3461 lbs.

Max load

515-580 kg 1135 - 1279 lbs.

Fuel tank capacity

36 l 9.51 US gal | 7.92 UK gal

Dimensions

Length

4070 mm 160.24 in.

Width

1655 mm 65.16 in.

Height

1600 mm 62.99 in.

Wheelbase

2525 mm 99.41 in.

Front track

1470 mm 57.87 in.

Rear (Back) track

1475 mm 58.07 in.

Ride height (ground clearance)

180 mm 7.09 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

4 gears, automatic transmission

Front suspension

Independent, McPherson type

Rear suspension

Semi-independent suspension, longitudinal arms with transverse torsion shafts

Front brakes

Ventilated discs

Rear brakes

Drum

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

175/65 R14

Wheel rim size

Specs of Daihatsu Sigra 1.2 (88 Hp) Automatic /2016, 2017, 2018, 2019/
