Cupra Raval 55 kWh (226 Hp) Electric | Technical specs, data, battery, electric range, Dimensions

Key specs

Cupra Raval 55 kWh (226 Hp) Electric /Hatchback 2026 - /

What is the body type of Cupra Raval?

Hatchback, 5 Doors, 5 Seats

What is the all-electric range of 55 kWh (226 Hp) Electric?

379-440 km
235 - 273 mi

What is the electricity consumption of Cupra Raval 55 kWh (226 Hp) Electric?

13.6-16.2 kWh/100 km
21.89 - 26.07 kWh/100 mi
154 - 129 MPGe
7.4 - 6.2 km/kWh
4.6 - 3.8 mi/kWh

How fast is 2026 Raval 55 kWh (226 Hp) Electric?

0-100 km/h: 6.8 sec
0-60 mph: 6.5 sec

What is the power output of Cupra Raval Hatchback 2026 55 kWh (226 Hp) Electric?

226 Hp, 290 Nm
214 lb.-ft.

What is the drivetrain of Cupra Raval Hatchback 2026 55 kWh (226 Hp) Electric?

Front wheel drive. BEV (Electric Vehicle). One electric motor drives the front wheels.

What is the length of 2026 Cupra Raval Hatchback?

4046 mm
159.29 in.

What is the width of 2026 Cupra Raval Hatchback?

1784 mm
70.24 in.

What is the kerb weight of 2026 Cupra Raval 55 kWh (226 Hp) Electric?

1610 kg
3549 lbs.

What is the trunk (boot) capacity of 2026 Cupra Raval Hatchback?

441 l
15.6 cu. ft.

What is the number of gears in What is the gearbox type of 2026 Cupra Raval 55 kWh (226 Hp) Electric?

1, automatic transmission

Cupra
- Cupra Raval
  - Raval
    - 55 kWh (226 Hp) Electric
    - 55 kWh (211 Hp) Electric
    - 38.5 kWh (135 Hp) Electric

Compare

General information

Brand

Cupra

Model

Raval

Generation

Raval

Modification (Engine)

55 kWh (226 Hp) Electric

Start of production

April, 2026 year

Powertrain Architecture

BEV (Electric Vehicle)

Body type

Hatchback

Seats

Doors

Looking for Cupra Raval on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Acceleration 0 - 100 km/h

6.8 sec

Acceleration 0 - 62 mph

6.8 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

6.5 sec

Weight-to-power ratio

7.1 kg/Hp, 140.4 Hp/tonne

Weight-to-torque ratio

5.6 kg/Nm, 180.1 Nm/tonne

Electric cars and hybrids specs

Gross battery capacity

55 kWh

Net (usable) battery capacity

51.5 kWh

Battery voltage

408 V

Battery technology

Lithium-ion (Li-Ion)

Battery location

Below the floor

Electric range (WLTP)

379-440 km 235 - 273 mi

Average Energy consumption (WLTP)

13.6-16.2 kWh/100 km 21.89 - 26.07 kWh/100 mi
154 - 129 MPGe
7.4 - 6.2 km/kWh
4.6 - 3.8 mi/kWh

Charging ports

Electric motor 1

Electric motor power

226 Hp

Electric motor Torque

290 Nm 214 lb.-ft.

Electric motor location

Front axle, Transverse

Electric motor type

Synchronous

System power

226 Hp

System torque

290 Nm 214 lb.-ft.

Volume and weights

Kerb Weight

1610 kg 3549 lbs.

Trunk (boot) space - minimum

441 l 15.6 cu. ft.

Dimensions

Length

4046 mm 159.29 in.

Width

1784 mm 70.24 in.

Width including mirrors

2000 mm 78.74 in.

Height

1514 mm 59.61 in.

Wheelbase

2599 mm 102.32 in.

Front track

1538 mm 60.55 in.

Rear (Back) track

1536 mm 60.47 in.

Front overhang

753 mm 29.65 in.

Rear overhang

693 mm 27.28 in.

Minimum turning circle (turning diameter)

11 m 36.09 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the front wheels.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Suspension strut, Coil spring, Independent, McPherson type

Rear suspension

Suspension strut, Coil spring, Torsion bar

Front brakes

Ventilated discs, 306x26 mm

Rear brakes

Disc, 300x12 mm

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Wheel rims size

18; 19
