Citroen SM 2.7 V6 (170 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Citroen SM 2.7 V6 (170 Hp) /Coupe, Liftback 1970 - 1972/

What is the body type of Citroen SM?

Coupe, Liftback, 3 Doors, 4 Seats

What is the fuel consumption and economy of Citroen SM 2.7 V6 (170 Hp)?

12.5 l/100 km
18.8 US mpg
22.6 UK mpg
8 km/l

How fast is 1970 SM 2.7 V6 (170 Hp)?

220 km/h | 137 mph
0-100 km/h: 8.9 sec
0-60 mph: 8.5 sec

What is the power output of Citroen SM Coupe, Liftback 1970 2.7 V6 (170 Hp)?

170 Hp, 230 Nm
170 lb.-ft.

What is the engine displacement of Citroen SM Coupe, Liftback 1970 2.7 V6 (170 Hp)?

2.7 l
2670 cm³
162.93 cu. in.

What is the number of cylinders in 1970 Citroen 2.7 V6 (170 Hp)?

6, V-engine

What is the drivetrain of Citroen SM Coupe, Liftback 1970 2.7 V6 (170 Hp)?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 1970 Citroen SM Coupe, Liftback?

4893 mm
192.64 in.

What is the width of 1970 Citroen SM Coupe, Liftback?

1836 mm
72.28 in.

What is the kerb weight of 1970 Citroen SM 2.7 V6 (170 Hp)?

1450 kg
3197 lbs.

What is the maximum permissible mass of 1970 Citroen SM 2.7 V6 (170 Hp)?

1800 kg
3968 lbs.

What are the number of gears and the gearbox type of 1970 Citroen SM 2.7 V6 (170 Hp)?

5, manual transmission

Citroen
- Citroen SM
  - SM
    - 2.7 V6 (170 Hp)

Compare

General information

Brand

Citroen

Model

Generation

Modification (Engine)

2.7 V6 (170 Hp)

Start of production

1970

End of production

1972

Powertrain Architecture

Internal Combustion engine

Body type

Coupe, Liftback

Seats

Doors

Looking for Citroen SM on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - combined

12.5 l/100 km 18.8 US mpg
22.6 UK mpg
8 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

8.9 sec

Acceleration 0 - 62 mph

8.9 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

8.5 sec

Maximum speed

220 km/h 137 mph

Weight-to-power ratio

8.5 kg/Hp, 117.2 Hp/tonne

Weight-to-torque ratio

6.3 kg/Nm, 158.6 Nm/tonne

Engine specs

Power

170 Hp @ 5500 rpm.

Power per litre

63.7 Hp/l

Torque

230 Nm @ 4000 rpm. 170 lb.-ft. @ 4000 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

C 114-1

Engine displacement

2670 cm³ 162.93 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

87 mm 3.43 in.

Piston Stroke

75 mm 2.95 in.

Compression ratio

9:1

Number of valves per cylinder

Fuel injection system

Carburettor

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

7 l 7.4 US qt | 6.16 UK qt

Engine oil specification

Coolant

13 l 13.74 US qt | 11.44 UK qt

Volume and weights

Kerb Weight

1450 kg 3197 lbs.

Max. weight

1800 kg 3968 lbs.

Max load

350 kg 772 lbs.

Fuel tank capacity

90 l 23.78 US gal | 19.8 UK gal

Dimensions

Length

4893 mm 192.64 in.

Width

1836 mm 72.28 in.

Height

1324 mm 52.13 in.

Ride height (ground clearance)

155 mm 6.1 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Hydro-pneumatic element

Rear suspension

Hydro-pneumatic element

Front brakes

Disc, 300 mm

Rear brakes

Disc, 256 mm

Steering type

Steering rack and pinion

Power steering

Hydraulic Steering

Tire size

195/70 R15

Specs of Citroen SM 2.7 V6 (170 Hp) /1970, 1971, 1972/
