Citroen GS 1.1 (56 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Citroen GS 1.1 (56 Hp) /Hatchback 1977 - 1979/

What is the body type of Citroen GS?

Hatchback, 4 Doors, 5 Seats

How fast is 1977 GS 1.1 (56 Hp)?

149 km/h | 93 mph
0-100 km/h: 17.5 sec
0-60 mph: 16.6 sec

What is the power output of Citroen GS Hatchback 1977 1.1 (56 Hp)?

56 Hp, 80 Nm
59 lb.-ft.

What is the engine displacement of Citroen GS Hatchback 1977 1.1 (56 Hp)?

1.1 l
1129 cm³
68.9 cu. in.

What is the number of cylinders in 1977 Citroen 1.1 (56 Hp)?

4, Boxer

What is the drivetrain of Citroen GS Hatchback 1977 1.1 (56 Hp)?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 1977 Citroen GS Hatchback?

4120 mm
162.2 in.

What is the width of 1977 Citroen GS Hatchback?

1608 mm
63.31 in.

What is the kerb weight of 1977 Citroen GS 1.1 (56 Hp)?

925 kg
2039 lbs.

What is the maximum permissible mass of 1977 Citroen GS 1.1 (56 Hp)?

1335 kg
2943 lbs.

What is the trunk (boot) capacity of 1977 Citroen GS Hatchback?

409 - 846 l
14.4 - 29.9 cu. ft.

What is the number of gears in What is the gearbox type of 1977 Citroen GS 1.1 (56 Hp)?

4, manual transmission

Citroen
- Citroen GS
  - GS
    - X 2 (65 Hp)
    - Birotor 2.0 (107 Hp)
    - 1.2 (59 Hp)
    - 1.1 (56 Hp)
    - 1.0 (56 Hp)

Compare

General information

Brand

Citroen

Model

Generation

Modification (Engine)

1.1 (56 Hp)

Start of production

1977 year

End of production

1979 year

Powertrain Architecture

Internal Combustion engine

Body type

Hatchback

Seats

Doors

Performance specs

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

17.5 sec

Acceleration 0 - 62 mph

17.5 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

16.6 sec

Maximum speed

149 km/h 93 mph

Weight-to-power ratio

16.5 kg/Hp, 60.5 Hp/tonne

Weight-to-torque ratio

11.6 kg/Nm, 86.5 Nm/tonne

Engine specs

Power

56 Hp @ 5750 rpm.

Power per litre

49.6 Hp/l

Torque

80 Nm @ 3500 rpm. 59 lb.-ft. @ 3500 rpm.

Engine Model/Code

G11/631

Engine displacement

1129 cm³ 68.9 cu. in.

Number of cylinders

Engine configuration

Boxer

Cylinder Bore

74 mm 2.91 in.

Piston Stroke

65.5 mm 2.58 in.

Compression ratio

9:1

Engine aspiration

Naturally aspirated engine

Engine oil capacity

3.5 l 3.7 US qt | 3.08 UK qt

Engine oil specification

Volume and weights

Kerb Weight

925 kg 2039 lbs.

Max. weight

1335 kg 2943 lbs.

Max load

410 kg 904 lbs.

Trunk (boot) space - minimum

409 l 14.4 cu. ft.

Trunk (boot) space - maximum

846 l 29.9 cu. ft.

Fuel tank capacity

43 l 11.36 US gal | 9.46 UK gal

Max. roof load

60 kg 132 lbs.

Permitted trailer load with brakes (12%)

800 kg 1764 lbs.

Permitted trailer load without brakes

460 kg 1014 lbs.

Dimensions

Length

4120 mm 162.2 in.

Width

1608 mm 63.31 in.

Height

1349 mm 53.11 in.

Wheelbase

2550 mm 100.39 in.

Front track

1378 mm 54.25 in.

Rear (Back) track

1328 mm 52.28 in.

Front overhang

818 mm 32.2 in.

Rear overhang

752 mm 29.61 in.

Ride height (ground clearance)

154 mm 6.06 in.

Minimum turning circle (turning diameter)

9.7 m 31.82 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

4 gears, manual transmission

Front suspension

Hydro-pneumatic element, Double wishbone

Rear suspension

Hydro-pneumatic element, Trailing arm

Front brakes

Disc

Rear brakes
