Citroen C5 X 1.6 (181 Hp) Plug-in Hybrid e-EAT | Technical specs, data, fuel consumption, Dimensions

Key specs

Citroen C5 X 1.6 (181 Hp) Plug-in Hybrid e-EAT /Station wagon (estate), Crossover 2023 - 2025/

What is the body type of Citroen C5 X?

Station wagon (estate), Crossover, 5 Doors, 5 Seats

What is the fuel consumption and economy of Citroen C5 X 1.6 (181 Hp) Plug-in Hybrid e-EAT?

1.8-1.9 l/100 km
130.7 - 123.8 US mpg
156.9 - 148.7 UK mpg
55.6 - 52.6 km/l

How environmentally friendly is Citroen C5 X 1.6 (181 Hp) Plug-in Hybrid e-EAT?

32-33 g/km CO₂
Euro 6e

What is the all-electric range of 1.6 (181 Hp) Plug-in Hybrid e-EAT?

54 km
34 mi

What is the electricity consumption of Citroen C5 X 1.6 (181 Hp) Plug-in Hybrid e-EAT?

16.7-16.8 kWh/100 km
26.88 - 27.04 kWh/100 mi
125 - 125 MPGe
6 - 6 km/kWh
3.7 - 3.7 mi/kWh

How fast is 2023 C5 X 1.6 (181 Hp) Plug-in Hybrid e-EAT?

225 km/h | 140 mph
0-100 km/h: 8.6 sec
0-60 mph: 8.2 sec

What is the power output of Citroen C5 X Station wagon (estate), Crossover 2023 1.6 (181 Hp) Plug-in Hybrid e-EAT?

181 Hp, 360 Nm
266 lb.-ft.

What is the engine displacement of Citroen C5 X Station wagon (estate), Crossover 2023 1.6 (181 Hp) Plug-in Hybrid e-EAT?

1.6 l
1598 cm³
97.52 cu. in.

What is the number of cylinders in 2023 Citroen 1.6 (181 Hp) Plug-in Hybrid e-EAT?

4, Inline

What is the drivetrain of Citroen C5 X Station wagon (estate), Crossover 2023 1.6 (181 Hp) Plug-in Hybrid e-EAT?

Front wheel drive. PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode.

What is the length of 2023 Citroen C5 X Station wagon (estate), Crossover?

4805 mm
189.17 in.

What is the width of 2023 Citroen C5 X Station wagon (estate), Crossover?

1815 mm
71.46 in.

What is the kerb weight of 2023 Citroen C5 X 1.6 (181 Hp) Plug-in Hybrid e-EAT?

1722-1781 kg
3796 - 3926 lbs.

What is the maximum permissible mass of 2023 Citroen C5 X 1.6 (181 Hp) Plug-in Hybrid e-EAT?

2185 kg
4817 lbs.

What is the trunk (boot) capacity of 2023 Citroen C5 X Station wagon (estate), Crossover?

485 l
17.1 cu. ft.

What is the number of gears in What is the gearbox type of 2023 Citroen C5 X 1.6 (181 Hp) Plug-in Hybrid e-EAT?

8, automatic transmission e-EAT

Citroen
- Citroen C5 X
  - C5 X
    - 1.6 PureTech (181 Hp) Automatic
    - 1.6 PureTech (225 Hp) Plug-in Hybrid e-EAT8
    - 1.6 PureTech (175 Hp) Aisin
    - 1.6 (181 Hp) Plug-in Hybrid e-EAT
    - 1.2 PureTech (131 Hp) Automatic
    - 1.2 (145 Hp) Hybrid e-DSC
    - 1.2 (136 Hp) Mild Hybrid e-DSC

Compare

General information

Brand

Citroen

Model

C5 X

Generation

C5 X

Modification (Engine)

1.6 (181 Hp) Plug-in Hybrid e-EAT

Start of production

February, 2023 year

End of production

February, 2025 year

Powertrain Architecture

PHEV (Plug-in Hybrid Electric Vehicle)

Body type

Station wagon (estate), Crossover

Seats

Doors

Performance specs

Combined fuel consumption (WLTP)

1.8-1.9 l/100 km 130.7 - 123.8 US mpg
156.9 - 148.7 UK mpg
55.6 - 52.6 km/l

CO₂ emissions (WLTP)

32-33 g/km

Fuel Type

Petrol / electricity

Acceleration 0 - 100 km/h

8.6 sec

Acceleration 0 - 62 mph

8.6 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

8.2 sec

Maximum speed

225 km/h 140 mph

Emission standard

Euro 6e

Weight-to-power ratio

9.5 kg/Hp, 105.1 Hp/tonne

Weight-to-torque ratio

4.8 kg/Nm, 209.1 Nm/tonne

Electric cars and hybrids specs

Gross battery capacity

12.4 kWh

Battery technology

Lithium-ion (Li-Ion)

Electric range (WLTP)

54 km 34 mi

Average Energy consumption (WLTP)

16.7-16.8 kWh/100 km 26.88 - 27.04 kWh/100 mi
125 - 125 MPGe
6 - 6 km/kWh
3.7 - 3.7 mi/kWh

Max speed (electric)

135 km/h 84 mph

Charging ports

Electric motor 1

Electric motor power

110 Hp @ 2500 rpm.

Electric motor Torque

320 Nm @ 500-2500 rpm. 236 lb.-ft. @ 500-2500 rpm.

Electric motor location

Between the combustion engine and the transmission

Electric motor type

Synchronous

System power

181 Hp

System torque

360 Nm 266 lb.-ft.

Internal combustion engine specs

Power

150 Hp @ 6000 rpm.

Power per litre

93.9 Hp/l

Torque

250 Nm @ 1750 rpm. 184 lb.-ft. @ 1750 rpm.

Engine layout

Front, Transverse

Engine Model/Code

EP6FDT

Engine displacement

1598 cm³ 97.52 cu. in.

Number of cylinders

Engine configuration

Inline

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Turbocharger, Intercooler

Engine oil capacity

4.3 l 4.54 US qt | 3.78 UK qt

Engine oil specification

Engine systems

Start & Stop System
Particulate filter

Volume and weights

Kerb Weight

1722-1781 kg 3796 - 3926 lbs.

Max. weight

2185 kg 4817 lbs.

Max load

404-463 kg 891 - 1021 lbs.

Trunk (boot) space - minimum

485 l 17.1 cu. ft.

Fuel tank capacity

40 l 10.57 US gal | 8.8 UK gal

Permitted trailer load with brakes (12%)

1350 kg 2976 lbs.

Permitted trailer load without brakes

750 kg 1653 lbs.

Permitted towbar download

70 kg 154 lbs.

Dimensions

Length

4805 mm 189.17 in.

Width

1815 mm 71.46 in.

Width with mirrors folded

1859 mm 73.19 in.

Width including mirrors

2062 mm 81.18 in.

Height

1485 mm 58.46 in.

Wheelbase

2785 mm 109.65 in.

Front track

1595 mm 62.8 in.

Rear (Back) track

1600 mm 62.99 in.

Front overhang

985 mm 38.78 in.

Rear overhang

1035 mm 40.75 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

8 gears, automatic transmission e-EAT

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

205/55 R19 97V

Wheel rims size

Specs of Citroen C5 X 1.6 (181 Hp) Plug-in Hybrid e-EAT /2023, 2024, 2025/
