Chrysler LHS II 3.5 i V6 24V (257 Hp) Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

Chrysler LHS II 3.5 i V6 24V (257 Hp) Automatic /Sedan 1999 - 2001/

What is the body type of Chrysler LHS II?

Sedan, 4 Doors, 5 Seats

How fast is 1999 LHS II 3.5 i V6 24V (257 Hp) Automatic?

210 km/h | 130 mph
0-100 km/h: 9.1 sec
0-60 mph: 8.6 sec

What is the power output of Chrysler LHS Sedan 1999 3.5 i V6 24V (257 Hp) Automatic?

257 Hp, 346 Nm
255 lb.-ft.

What is the engine displacement of Chrysler LHS Sedan 1999 3.5 i V6 24V (257 Hp) Automatic?

3.5 l
3518 cm³
214.68 cu. in.

What is the number of cylinders in 1999 Chrysler 3.5 i V6 24V (257 Hp) Automatic?

6, V-engine

What is the drivetrain of Chrysler LHS II Sedan 1999 3.5 i V6 24V (257 Hp) Automatic?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 1999 Chrysler LHS Sedan?

5275 mm
207.68 in.

What is the width of 1999 Chrysler LHS Sedan?

1890 mm
74.41 in.

What is the kerb weight of 1999 Chrysler LHS II 3.5 i V6 24V (257 Hp) Automatic?

1625 kg
3583 lbs.

What is the maximum permissible mass of 1999 Chrysler LHS II 3.5 i V6 24V (257 Hp) Automatic?

2100 kg
4630 lbs.

What is the trunk (boot) capacity of 1999 Chrysler LHS Sedan?

530 l
18.7 cu. ft.

What is the number of gears in What is the gearbox type of 1999 Chrysler LHS II 3.5 i V6 24V (257 Hp) Automatic?

4, automatic transmission

Chrysler
- Chrysler LHS
  - LHS II
    - 3.5 i V6 24V (257 Hp) Automatic
    - 3.5 i V6 24V (218 Hp) Automatic

Compare

General information

Brand

Chrysler

Model

LHS

Generation

LHS II

Modification (Engine)

3.5 i V6 24V (257 Hp) Automatic

Start of production

1999 year

End of production

2001 year

Powertrain Architecture

Internal Combustion engine

Body type

Sedan

Seats

Doors

Looking for Chrysler LHS on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

15 l/100 km 15.7 US mpg
18.8 UK mpg
6.7 km/l

Fuel consumption (economy) - extra urban

8 l/100 km 29.4 US mpg
35.3 UK mpg
12.5 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

9.1 sec

Acceleration 0 - 62 mph

9.1 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

8.6 sec

Maximum speed

210 km/h 130 mph

Weight-to-power ratio

6.3 kg/Hp, 158.2 Hp/tonne

Weight-to-torque ratio

4.7 kg/Nm, 212.9 Nm/tonne

Engine specs

Power

257 Hp @ 6400 rpm.

Power per litre

73.1 Hp/l

Torque

346 Nm @ 3950 rpm. 255 lb.-ft. @ 3950 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

EGG

Engine displacement

3518 cm³ 214.68 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

96 mm 3.78 in.

Piston Stroke

81 mm 3.19 in.

Compression ratio

10:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

OHC

Engine oil capacity

4.7 l 4.97 US qt | 4.14 UK qt

Engine oil specification

Coolant

8.9 l 9.4 US qt | 7.83 UK qt

Volume and weights

Kerb Weight

1625 kg 3583 lbs.

Max. weight

2100 kg 4630 lbs.

Max load

475 kg 1047 lbs.

Trunk (boot) space - minimum

530 l 18.7 cu. ft.

Fuel tank capacity

68 l 17.96 US gal | 14.96 UK gal

Dimensions

Length

5275 mm 207.68 in.

Width

1890 mm 74.41 in.

Height

1420 mm 55.91 in.

Wheelbase

2870 mm 112.99 in.

Front track

1575 mm 62.01 in.

Rear (Back) track

1565 mm 61.61 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

4 gears, automatic transmission

Front suspension

Wishbone

Rear suspension

Coil spring

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Hydraulic Steering

Tires size

225/55 R17

Specs of Chrysler LHS II 3.5 i V6 24V (257 Hp) Automatic /1999, 2000, 2001/
