Chevrolet Avalanche II 5.3 V8 Vortec (325 Hp) Hydra-Matic | Technical specs, data, fuel consumption, Dimensions

Key specs

Chevrolet Avalanche II 5.3 V8 Vortec (325 Hp) Hydra-Matic /Pick-up 2006 - 2009/

What is the body type of Chevrolet Avalanche II?

Pick-up, 4 Doors, 5-6 Seats

What is the fuel consumption and economy of Chevrolet Avalanche II 5.3 V8 Vortec (325 Hp) Hydra-Matic?

13.8 l/100 km
17 US mpg
20.5 UK mpg
7.2 km/l

What is the power output of Chevrolet Avalanche Pick-up 2006 5.3 V8 Vortec (325 Hp) Hydra-Matic?

325 Hp, 461 Nm
340 lb.-ft.

What is the engine displacement of Chevrolet Avalanche Pick-up 2006 5.3 V8 Vortec (325 Hp) Hydra-Matic?

5.3 l
5328 cm³
325.13 cu. in.

What is the number of cylinders in 2006 Chevrolet 5.3 V8 Vortec (325 Hp) Hydra-Matic?

8, V-engine

What is the drivetrain of Chevrolet Avalanche II Pick-up 2006 5.3 V8 Vortec (325 Hp) Hydra-Matic?

Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

What is the length of 2006 Chevrolet Avalanche Pick-up?

5621 mm
221.3 in.

What is the width of 2006 Chevrolet Avalanche Pick-up?

2010 mm
79.13 in.

What is the kerb weight of 2006 Chevrolet Avalanche II 5.3 V8 Vortec (325 Hp) Hydra-Matic?

2485 kg
5478 lbs.

What is the maximum permissible mass of 2006 Chevrolet Avalanche II 5.3 V8 Vortec (325 Hp) Hydra-Matic?

3084 kg
6799 lbs.

What is the trunk (boot) capacity of 2006 Chevrolet Avalanche Pick-up?

1289 l
45.5 cu. ft.

What is the number of gears in What is the gearbox type of 2006 Chevrolet Avalanche II 5.3 V8 Vortec (325 Hp) Hydra-Matic?

4, automatic transmission Hydra-Matic

Chevrolet
- Chevrolet Avalanche
  - Avalanche II

Compare

General information

Brand

Chevrolet

Model

Avalanche

Generation

Avalanche II

Modification (Engine)

5.3 V8 Vortec (325 Hp) Hydra-Matic

Start of production

April, 2006 year

End of production

2009 year

Powertrain Architecture

Internal Combustion engine

Body type

Pick-up

Seats

5-6

Doors

Performance specs

Fuel consumption (economy) - urban

15.7 l/100 km 15 US mpg
18 UK mpg
6.4 km/l

Fuel consumption (economy) - urban (Ethanol - E85)

19.6 l/100 km

Fuel consumption (economy) - extra urban

11.2 l/100 km 21 US mpg
25.2 UK mpg
8.9 km/l

Fuel consumption (economy) - extra urban (Ethanol - E85)

14.7 l/100 km

Fuel consumption (economy) - combined

13.8 l/100 km 17 US mpg
20.5 UK mpg
7.2 km/l

Fuel consumption (economy) - combined (Ethanol - E85)

18.1 l/100 km

Fuel Type

Petrol / Ethanol - E85

Weight-to-power ratio

7.6 kg/Hp, 130.8 Hp/tonne

Weight-to-torque ratio

5.4 kg/Nm, 185.5 Nm/tonne

Engine specs

Power

325 Hp @ 5200 rpm.

Power per litre

61 Hp/l

Torque

461 Nm @ 4200 rpm. 340 lb.-ft. @ 4200 rpm.

Maximum engine speed

6000 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

LY5, LMG

Engine displacement

5328 cm³ 325.13 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

96 mm 3.78 in.

Piston Stroke

92 mm 3.62 in.

Compression ratio

9.9:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

OHV

Engine oil capacity

5.7 l 6.02 US qt | 5.02 UK qt

Engine oil specification

Coolant

15.9 l 16.8 US qt | 13.99 UK qt

Volume and weights

Kerb Weight

2485 kg 5478 lbs.

Max. weight

3084 kg 6799 lbs.

Max load

599 kg 1321 lbs.

Trunk (boot) space - minimum

1289 l 45.5 cu. ft.

Fuel tank capacity

119 l 31.44 US gal | 26.18 UK gal

Permitted trailer load with brakes (12%)

3628 kg 7998 lbs.

Dimensions

Length

5621 mm 221.3 in.

Width

2010 mm 79.13 in.

Height

1945 mm 76.57 in.

Wheelbase

3302 mm 130 in.

Front track

1732 mm 68.19 in.

Rear (Back) track

1702 mm 67.01 in.

Ride height (ground clearance)

231 mm 9.09 in.

Minimum turning circle (turning diameter)

13.1 m 42.98 ft.

Approach angle

16.78°

Departure angle

20.05°

Wading depth

819 mm 32.24 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

4 gears, automatic transmission Hydra-Matic

Front suspension

Torsion bar

Rear suspension

Independent multi-link suspension

Front brakes

Ventilated discs, 330.2x30 mm

Rear brakes

Disc, 345x20 mm

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

265/70 R17; 265/65 R18; 275/55 R20

Wheel rims size

7.5J x 17; 8.0J x 18; 8.5J x 20

Specs of Chevrolet Avalanche II 5.3 V8 Vortec (325 Hp) Hydra-Matic /2006, 2007, 2008, 2009/
