Cadillac XT6 2.0 Turbo (238 Hp) AWD Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

Cadillac XT6 2.0 Turbo (238 Hp) AWD Automatic /SUV 2020 - /

What is the body type of Cadillac XT6?

SUV, 5 Doors, 6-7 Seats

What is the power output of Cadillac XT6 SUV 2020 2.0 Turbo (238 Hp) AWD Automatic?

238 Hp, 350 Nm
258 lb.-ft.

What is the engine displacement of Cadillac XT6 SUV 2020 2.0 Turbo (238 Hp) AWD Automatic?

2.0 l
1998 cm³
121.93 cu. in.

What is the number of cylinders in 2020 Cadillac 2.0 Turbo (238 Hp) AWD Automatic?

4, Inline

What is the drivetrain of Cadillac XT6 SUV 2020 2.0 Turbo (238 Hp) AWD Automatic?

All wheel drive (4x4). Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary.

What is the length of 2020 Cadillac XT6 SUV?

5042 mm
198.5 in.

What is the width of 2020 Cadillac XT6 SUV?

1963 mm
77.28 in.

What is the kerb weight of 2020 Cadillac XT6 2.0 Turbo (238 Hp) AWD Automatic?

2071 kg
4566 lbs.

What is the trunk (boot) capacity of 2020 Cadillac XT6 SUV?

357 - 2229 l
12.6 - 78.7 cu. ft.

What are the number of gears and the gearbox type of 2020 Cadillac XT6 2.0 Turbo (238 Hp) AWD Automatic?

9, automatic transmission

Cadillac
- Cadillac XT6
  - XT6
    - 3.6 V6 (311 Hp) AWD Automatic
    - 3.6 V6 (311 Hp) Automatic
    - 2.0 Turbo (238 Hp) AWD Automatic
    - 2.0 Turbo (238 Hp) Automatic

Compare

General information

Brand

Cadillac

Model

XT6

Generation

XT6

Modification (Engine)

2.0 Turbo (238 Hp) AWD Automatic

Start of production

December, 2020

Powertrain Architecture

Internal Combustion engine

Body type

SUV

Seats

6-7

Doors

Looking for Cadillac XT6 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban (EPA)

11.2 l/100 km 21 US mpg
25.2 UK mpg
8.9 km/l

Fuel consumption (economy) - extra urban (EPA)

9 l/100 km 26.1 US mpg
31.4 UK mpg
11.1 km/l

Fuel Type

Petrol (Gasoline)

Weight-to-power ratio

8.7 kg/Hp, 114.9 Hp/tonne

Weight-to-torque ratio

5.9 kg/Nm, 169 Nm/tonne

Engine specs

Power

238 Hp @ 5000 rpm.

Power per litre

119.1 Hp/l

Torque

350 Nm @ 1500-4000 rpm. 258 lb.-ft. @ 1500-4000 rpm.

Engine Model/Code

LSY

Engine displacement

1998 cm³ 121.93 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

83 mm 3.27 in.

Piston Stroke

92.3 mm 3.63 in.

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Turbocharger, Intercooler

Valvetrain

DOHC, VVT

Engine oil capacity

5 l 5.28 US qt | 4.4 UK qt

Engine oil specification

Coolant

11.4 l 12.05 US qt | 10.03 UK qt

Engine systems

Start & Stop System

Volume and weights

Kerb Weight

2071 kg 4566 lbs.

Trunk (boot) space - minimum

357 l 12.6 cu. ft.

Trunk (boot) space - maximum

2229 l 78.7 cu. ft.

Fuel tank capacity

83 l 21.93 US gal | 18.26 UK gal

Permitted trailer load with brakes (12%)

454 kg 1001 lbs.

Dimensions

Length

5042 mm 198.5 in.

Width

1963 mm 77.28 in.

Height

1784 mm 70.24 in.

Wheelbase

2863 mm 112.72 in.

Front track

1687 mm 66.42 in.

Rear (Back) track

1681 mm 66.18 in.

Ride height (ground clearance)

169 mm 6.65 in.

Minimum turning circle (turning diameter)

11.8 m 38.71 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

9 gears, automatic transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Independent multi-link spring suspension with anti-roll bar

Front brakes

Ventilated discs, 321x30 mm

Rear brakes

Ventilated discs, 315x23 mm

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

235/65 R18

Wheel rim size

Specs of Cadillac XT6 2.0 Turbo (238 Hp) AWD Automatic /2020, 2021, 2022, 2023, 2024, 2025, 2026/
