BMW Z3 (E36/7) 1.9 (118 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

BMW Z3 (E36/7) 1.9 (118 Hp) /Roadster 1998 - 2003/

What is the body type of BMW Z3 (E36/7)?

Roadster, 2 Doors, 2 Seats

How fast is 1998 Z3 (E36/7) 1.9 (118 Hp)?

196 km/h | 122 mph
0-100 km/h: 10.4 sec
0-60 mph: 9.9 sec

What is the power output of BMW Z3 Roadster 1998 1.9 (118 Hp)?

118 Hp, 190 Nm
140 lb.-ft.

What is the engine displacement of BMW Z3 Roadster 1998 1.9 (118 Hp)?

1.9 l
1895 cm³
115.64 cu. in.

What is the number of cylinders in 1998 BMW 1.9 (118 Hp)?

4, Inline

What is the drivetrain of BMW Z3 (E36/7) Roadster 1998 1.9 (118 Hp)?

Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

What is the length of 1998 BMW Z3 Roadster?

4050 mm
159.45 in.

What is the width of 1998 BMW Z3 Roadster?

1740 mm
68.5 in.

What is the kerb weight of 1998 BMW Z3 (E36/7) 1.9 (118 Hp)?

1220 kg
2690 lbs.

What is the maximum permissible mass of 1998 BMW Z3 (E36/7) 1.9 (118 Hp)?

1490 kg
3285 lbs.

What is the trunk (boot) capacity of 1998 BMW Z3 Roadster?

165 l
5.8 cu. ft.

What are the number of gears and the gearbox type of 1998 BMW Z3 (E36/7) 1.9 (118 Hp)?

5, manual transmission

BMW
- BMW Z3
  - Z3 (E36/7)

Compare

General information

Brand

BMW

Model

Generation

Z3 (E36/7)

Modification (Engine)

1.9 (118 Hp)

Start of production

1998

End of production

2003

Powertrain Architecture

Internal Combustion engine

Body type

Roadster

Seats

Doors

Looking for BMW Z3 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

11 l/100 km 21.4 US mpg
25.7 UK mpg
9.1 km/l

Fuel consumption (economy) - extra urban

6 l/100 km 39.2 US mpg
47.1 UK mpg
16.7 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

10.4 sec

Acceleration 0 - 62 mph

10.4 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

9.9 sec

Maximum speed

196 km/h 122 mph

Weight-to-power ratio

10.3 kg/Hp, 96.7 Hp/tonne

Weight-to-torque ratio

6.4 kg/Nm, 155.7 Nm/tonne

Engine specs

Power

118 Hp @ 5500 rpm.

Power per litre

62.3 Hp/l

Torque

190 Nm @ 3500 rpm. 140 lb.-ft. @ 3500 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

M43TUB19

Engine displacement

1895 cm³ 115.64 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

85 mm 3.35 in.

Piston Stroke

83.5 mm 3.29 in.

Compression ratio

9.7:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

OHC

Engine oil capacity

4 l 4.23 US qt | 3.52 UK qt

Engine oil specification

Coolant

6.6 l 6.97 US qt | 5.81 UK qt

Volume and weights

Kerb Weight

1220 kg 2690 lbs.

Max. weight

1490 kg 3285 lbs.

Max load

270 kg 595 lbs.

Trunk (boot) space - minimum

165 l 5.8 cu. ft.

Fuel tank capacity

51 l 13.47 US gal | 11.22 UK gal

Dimensions

Length

4050 mm 159.45 in.

Width

1740 mm 68.5 in.

Height

1288 mm 50.71 in.

Wheelbase

2446 mm 96.3 in.

Front track

1411 mm 55.55 in.

Rear (Back) track

1492 mm 58.74 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Suspension strut

Rear suspension

Coil spring

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Hydraulic Steering

Tire size

225/50 R16

Wheel rim size

Specs of BMW Z3 (E36/7) 1.9 (118 Hp) /1998, 1999, 2000, 2001, 2002, 2003/
