BMW XM (G09) Label Red 4.4 V8 (748 Hp) Plug-in Hybrid xDrive Steptronic | Technical specs, data, fuel consumption, Dimensions

Key specs

BMW XM (G09) Label Red 4.4 V8 (748 Hp) Plug-in Hybrid xDrive Steptronic /SUV 2023 - /

What is the body type of BMW XM (G09)?

SUV, 5 Doors, 5 Seats

What is the fuel consumption and economy of BMW XM (G09) Label Red 4.4 V8 (748 Hp) Plug-in Hybrid xDrive Steptronic?

1.6-1.7 l/100 km
147 - 138.4 US mpg
176.6 - 166.2 UK mpg
62.5 - 58.8 km/l

How environmentally friendly is BMW XM Label Red 4.4 V8 (748 Hp) Plug-in Hybrid xDrive Steptronic?

35-39 g/km CO₂
Euro 6d

What is the all-electric range of Label Red 4.4 V8 (748 Hp) Plug-in Hybrid xDrive Steptronic?

75-83 km
47 - 52 mi

What is the electricity consumption of BMW XM (G09) Label Red 4.4 V8 (748 Hp) Plug-in Hybrid xDrive Steptronic?

33-34.5 kWh/100 km
53.11 - 55.52 kWh/100 mi
63 - 61 MPGe
3 - 2.9 km/kWh
1.9 - 1.8 mi/kWh

How fast is 2023 XM (G09) Label Red 4.4 V8 (748 Hp) Plug-in Hybrid xDrive Steptronic?

250 km/h | 155 mph
0-100 km/h: 3.8 sec
0-60 mph: 3.6 sec

What is the power output of BMW XM SUV 2023 Label Red 4.4 V8 (748 Hp) Plug-in Hybrid xDrive Steptronic?

748 Hp, 1000 Nm
738 lb.-ft.

What is the engine displacement of BMW XM SUV 2023 Label Red 4.4 V8 (748 Hp) Plug-in Hybrid xDrive Steptronic?

4.4 l
4395 cm³
268.2 cu. in.

What is the number of cylinders in 2023 BMW Label Red 4.4 V8 (748 Hp) Plug-in Hybrid xDrive Steptronic?

8, V-engine

What is the drivetrain of BMW XM (G09) SUV 2023 Label Red 4.4 V8 (748 Hp) Plug-in Hybrid xDrive Steptronic?

All wheel drive (4x4). PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) and the electric motor permanently drive the four wheels of the car with the ability to work in full electric or mixed mode.

What is the number of gears in What is the gearbox type of 2023 BMW XM (G09) Label Red 4.4 V8 (748 Hp) Plug-in Hybrid xDrive Steptronic?

8, automatic transmission Steptronic

BMW
- BMW XM
  - XM (G09)
    - Label Red 4.4 V8 (748 Hp) Plug-in Hybrid xDrive Steptronic
    - 50e (476 Hp) Plug-in Hybrid M xDrive M Steptronic
    - 4.4 V8 (653 Hp) Plug-in Hybrid xDrive Steptronic

Compare

General information

Brand

BMW

Model

Generation

XM (G09)

Modification (Engine)

Label Red 4.4 V8 (748 Hp) Plug-in Hybrid xDrive Steptronic

Start of production

August, 2023 year

Powertrain Architecture

PHEV (Plug-in Hybrid Electric Vehicle)

Body type

SUV

Seats

Doors

Looking for BMW XM on the used-car market?

Check its history →

Performance specs

Combined fuel consumption (WLTP)

1.6-1.7 l/100 km 147 - 138.4 US mpg
176.6 - 166.2 UK mpg
62.5 - 58.8 km/l

CO₂ emissions (WLTP)

35-39 g/km

Fuel Type

Petrol / electricity

Acceleration 0 - 100 km/h

3.8 sec

Acceleration 0 - 62 mph

3.8 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

3.6 sec

Maximum speed

250 km/h, Electronically limited 155 mph

Emission standard

Euro 6d

Electric cars and hybrids specs

Net (usable) battery capacity

25.7 kWh

Battery technology

Lithium-ion (Li-Ion)

Battery location

Below the floor

Electric range (WLTP)

75-83 km 47 - 52 mi

Average Energy consumption (WLTP)

33-34.5 kWh/100 km 53.11 - 55.52 kWh/100 mi
63 - 61 MPGe
3 - 2.9 km/kWh
1.9 - 1.8 mi/kWh

Max speed (electric)

140 km/h 87 mph

Charging ports

Electric motor 1

Electric motor power

197 Hp

Electric motor Torque

280 Nm 207 lb.-ft.

Electric motor location

Between the combustion engine and the transmission

Electric motor type

Synchronous

System power

748 Hp

System torque

1000 Nm 738 lb.-ft.

Internal combustion engine specs

Power

585 Hp @ 5600 rpm.

Power per litre

133.1 Hp/l

Torque

750 Nm @ 1800-5400 rpm. 553 lb.-ft. @ 1800-5400 rpm.

Engine layout

Front, Longitudinal

Engine displacement

4395 cm³ 268.2 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

88.3 mm 3.48 in.

Piston Stroke

89.5 mm 3.52 in.

Compression ratio

10.5:1

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

TwinPower Turbo, Intercooler

Valvetrain

VALVETRONIC, Double-VANOS

Engine oil capacity

10.75 l 11.36 US qt | 9.46 UK qt

Engine oil specification

Engine systems

Start & Stop System
Particulate filter

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) and the electric motor permanently drive the four wheels of the car with the ability to work in full electric or mixed mode.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

8 gears, automatic transmission Steptronic

Front suspension

Double wishbone

Rear suspension

Independent multi-link suspension

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

Front wheel tires: 275/45 R21
Rear wheel tires: 315/40 R21

Wheel rims size

Front wheel rims: 21
Rear wheel rims: 21

Specs of BMW XM (G09) Label Red 4.4 V8 (748 Hp) Plug-in Hybrid xDrive Steptronic /2023, 2024, 2025, 2026/
