BMW iX (i20) 76.6 kWh (326 Hp) xDrive40 | Technical specs, data, battery, electric range, Dimensions

Key specs

BMW iX (i20) 76.6 kWh (326 Hp) xDrive40 /SAV 2021 - 2025/

What is the body type of BMW iX (i20)?

SAV, 5 Doors, 5 Seats

What is the all-electric range of 76.6 kWh (326 Hp) xDrive40?

372-425 km
231 - 264 mi

What is the electricity consumption of BMW iX (i20) 76.6 kWh (326 Hp) xDrive40?

19.4-22.5 kWh/100 km
31.22 - 36.21 kWh/100 mi
108 - 93 MPGe
5.2 - 4.4 km/kWh
3.2 - 2.8 mi/kWh

How fast is 2021 iX (i20) 76.6 kWh (326 Hp) xDrive40?

200 km/h | 124 mph
0-100 km/h: 6.1 sec
0-60 mph: 5.8 sec

What is the power output of BMW iX SAV 2021 76.6 kWh (326 Hp) xDrive40?

326 Hp, 630 Nm
465 lb.-ft.

What is the drivetrain of BMW iX (i20) SAV 2021 76.6 kWh (326 Hp) xDrive40?

All wheel drive (4x4). BEV (Electric Vehicle). One electric motor drives the front wheels, one electric motor drives the rear wheels.

What is the length of 2021 BMW iX SAV?

4953 mm
195 in.

What is the width of 2021 BMW iX SAV?

1967 mm
77.44 in.

What is the kerb weight of 2021 BMW iX (i20) 76.6 kWh (326 Hp) xDrive40?

2365 kg
5214 lbs.

What is the maximum permissible mass of 2021 BMW iX (i20) 76.6 kWh (326 Hp) xDrive40?

3010 kg
6636 lbs.

What is the trunk (boot) capacity of 2021 BMW iX SAV?

500 - 1750 l
17.7 - 61.8 cu. ft.

What are the number of gears and the gearbox type of 2021 BMW iX (i20) 76.6 kWh (326 Hp) xDrive40?

1, automatic transmission

BMW
- BMW iX
  - iX (i20)
    - M60 111.5 kWh (619 Hp) xDrive
    - 76.6 kWh (326 Hp) xDrive40
    - 111.5 kWh (523 Hp) xDrive50

Compare

General information

Brand

BMW

Model

Generation

iX (i20)

Modification (Engine)

76.6 kWh (326 Hp) xDrive40

Start of production

2021

End of production

2025

Powertrain Architecture

BEV (Electric Vehicle)

Body type

SAV

Seats

Doors

Looking for BMW iX on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Acceleration 0 - 100 km/h

6.1 sec

Acceleration 0 - 62 mph

6.1 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

5.8 sec

Maximum speed

200 km/h, Electronically limited 124 mph

Weight-to-power ratio

7.3 kg/Hp, 137.8 Hp/tonne

Weight-to-torque ratio

3.8 kg/Nm, 266.4 Nm/tonne

Electric and hybrid car specs

Gross battery capacity

76.6 kWh

Net (usable) battery capacity

71 kWh

Battery voltage

330.3 V

Battery technology

Lithium nickel manganese cobalt oxides (Li-NMC)

Battery location

Below the floor

Electric range (WLTP)

372-425 km 231 - 264 mi

Average Energy consumption (WLTP)

19.4-22.5 kWh/100 km 31.22 - 36.21 kWh/100 mi
108 - 93 MPGe
5.2 - 4.4 km/kWh
3.2 - 2.8 mi/kWh

Charging ports

Charging times

Electric motor 1

Electric motor power

272 Hp

Electric motor Torque

352 Nm 260 lb.-ft.

Electric motor location

Front axle, Transverse

Electric motor 2

Electric motor power

340 Hp

Electric motor Torque

400 Nm 295 lb.-ft.

Electric motor location

Rear axle, Transverse

System power

326 Hp

System torque

630 Nm 465 lb.-ft.

Volume and weights

Kerb Weight

2365 kg 5214 lbs.

Max. weight

3010 kg 6636 lbs.

Max load

645 kg 1422 lbs.

Trunk (boot) space - minimum

500 l 17.7 cu. ft.

Trunk (boot) space - maximum

1750 l 61.8 cu. ft.

Max. roof load

75 kg 165 lbs.

Permitted trailer load with brakes (12%)

2500 kg 5512 lbs.

Permitted trailer load without brakes

750 kg 1653 lbs.

Permitted towbar download

100 kg 220 lbs.

Dimensions

Length

4953 mm 195 in.

Width

1967 mm 77.44 in.

Height

1695 mm 66.73 in.

Wheelbase

3000 mm 118.11 in.

Front track

1679 mm 66.1 in.

Rear (Back) track

1709 mm 67.28 in.

Ride height (ground clearance)

202 mm 7.95 in.

Drag coefficient (C_d)

0.25

Minimum turning circle (turning diameter)

12.8 m 41.99 ft.

Approach angle

18.8°

Departure angle

20.7°

Ramp-over (breakover) angle

17.5°

Wading depth

379 mm 14.92 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the front wheels, one electric motor drives the rear wheels.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Double wishbone

Rear suspension

Independent multi-link suspension

Front brakes

Ventilated discs, 348x30 mm

Rear brakes

Ventilated discs, 330x20 mm

Assisting systems

ABS (Anti-lock braking system)
4-wheel steering (4WS, active rear steering)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

235/60 R20

Wheel rim size

8.5J x 20

Specs of BMW iX (i20) 76.6 kWh (326 Hp) xDrive40 /2021, 2022, 2023, 2024, 2025/
