BMW i5 Sedan (G60) M60 81.2 kWh (601 Hp) xDrive | Technical specs, data, battery, electric range, Dimensions

Key specs

BMW i5 Sedan (G60) M60 81.2 kWh (601 Hp) xDrive /Sedan 2023 - /

What is the body type of BMW i5 Sedan (G60)?

Sedan, 4 Doors, 5 Seats

What is the all-electric range of M60 81.2 kWh (601 Hp) xDrive?

455-516 km
283 - 321 mi

What is the electricity consumption of BMW i5 Sedan (G60) M60 81.2 kWh (601 Hp) xDrive?

18.2-20.6 kWh/100 km
29.29 - 33.15 kWh/100 mi
115 - 102 MPGe
5.5 - 4.9 km/kWh
3.4 - 3 mi/kWh

How fast is 2023 i5 Sedan (G60) M60 81.2 kWh (601 Hp) xDrive?

230 km/h | 143 mph
0-100 km/h: 3.8 sec
0-60 mph: 3.6 sec

What is the power output of BMW i5 Sedan 2023 M60 81.2 kWh (601 Hp) xDrive?

601 Hp, 820 Nm
605 lb.-ft.

What is the drivetrain of BMW i5 Sedan (G60) Sedan 2023 M60 81.2 kWh (601 Hp) xDrive?

All wheel drive (4x4). BEV (Electric Vehicle). One electric motor drives the front wheels, one electric motor drives the rear wheels.

What is the length of 2023 BMW i5 Sedan?

5060 mm
199.21 in.

What is the width of 2023 BMW i5 Sedan?

1900 mm
74.8 in.

What is the kerb weight of 2023 BMW i5 Sedan (G60) M60 81.2 kWh (601 Hp) xDrive?

2305 kg
5082 lbs.

What is the maximum permissible mass of 2023 BMW i5 Sedan (G60) M60 81.2 kWh (601 Hp) xDrive?

2895 kg
6382 lbs.

What is the trunk (boot) capacity of 2023 BMW i5 Sedan?

490 l
17.3 cu. ft.

What is the number of gears in 2023 BMW i5 Sedan (G60) M60 81.2 kWh (601 Hp) xDrive?

1, automatic transmission

BMW
- BMW i5
  - i5 Sedan (G60)
    - M60 81.2 kWh (601 Hp) xDrive
    - 83.9 kWh (394 Hp) xDrive40
    - 81.2 kWh (340 Hp) eDrive40

Compare

General information

Brand

BMW

Model

Generation

i5 Sedan (G60)

Modification (Engine)

M60 81.2 kWh (601 Hp) xDrive

Start of production

October, 2023 year

Powertrain Architecture

BEV (Electric Vehicle)

Body type

Sedan

Seats

Doors

Looking for BMW i5 on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Acceleration 0 - 100 km/h

3.8 sec

Acceleration 0 - 62 mph

3.8 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

3.6 sec

Maximum speed

230 km/h, Electronically limited 143 mph

Weight-to-power ratio

3.8 kg/Hp, 260.7 Hp/tonne

Weight-to-torque ratio

2.8 kg/Nm, 355.7 Nm/tonne

Electric cars and hybrids specs

Net (usable) battery capacity

81.2 kWh

Battery voltage

400 V

Battery technology

Lithium-ion (Li-Ion)

Battery location

Below the floor

Electric range (WLTP)

455-516 km 283 - 321 mi

Average Energy consumption (WLTP)

18.2-20.6 kWh/100 km 29.29 - 33.15 kWh/100 mi
115 - 102 MPGe
5.5 - 4.9 km/kWh
3.4 - 3 mi/kWh

Charging ports

Electric motor 1

Electric motor power

340 Hp @ 8000 rpm.

Electric motor Torque

430 Nm @ 0-5000 rpm. 317 lb.-ft. @ 0-5000 rpm.

Electric motor location

Rear axle, Transverse

Electric motor type

Synchronous

Electric motor 2

Electric motor power

261 Hp @ 8000 rpm.

Electric motor Torque

365 Nm @ 0-5000 rpm. 269 lb.-ft. @ 0-5000 rpm.

Electric motor location

Front axle, Transverse

Electric motor type

Synchronous

System power

601 Hp

System torque

820 Nm 605 lb.-ft.

Volume and weights

Kerb Weight

2305 kg 5082 lbs.

Max. weight

2895 kg 6382 lbs.

Max load

590 kg 1301 lbs.

Trunk (boot) space - minimum

490 l 17.3 cu. ft.

Max. roof load

75 kg 165 lbs.

Permitted trailer load with brakes (12%)

2000 kg 4409 lbs.

Permitted trailer load without brakes

750 kg 1653 lbs.

Permitted towbar download

80 kg 176 lbs.

Dimensions

Length

5060 mm 199.21 in.

Width

1900 mm 74.8 in.

Width including mirrors

2156 mm 84.88 in.

Height

1505 mm 59.25 in.

Wheelbase

2995 mm 117.91 in.

Front track

1634 mm 64.33 in.

Rear (Back) track

1624 mm 63.94 in.

Front overhang

945 mm 37.2 in.

Rear overhang

1120 mm 44.09 in.

Ride height (ground clearance)

136 mm 5.35 in.

Drag coefficient (C_d)

0.25

Minimum turning circle (turning diameter)

11.9 m 39.04 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the front wheels, one electric motor drives the rear wheels.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Double wishbone

Rear suspension

Independent multi-link suspension

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)
4-wheel steering (4WS, active rear steering)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

Front wheel tires: 245/45 R19 102Y XL
Rear wheel tires: 275/40 R19 105Y XL

Wheel rims size

Front wheel rims: 8.5J x 19
Rear wheel rims: 10J x 19

Specs of BMW i5 Sedan (G60) M60 81.2 kWh (601 Hp) xDrive /2023, 2024, 2025, 2026/
