Audi S2 2.2i Turbo 20V (230 Hp) quattro | Technical specs, data, fuel consumption, Dimensions

Key specs

Audi S2 2.2i Turbo 20V (230 Hp) quattro /Sedan 1992 - 1995/

What is the body type of Audi S2?

Sedan, 4 Doors, 5 Seats

How fast is 1992 S2 2.2i Turbo 20V (230 Hp) quattro?

246 km/h | 153 mph
0-100 km/h: 6 sec
0-60 mph: 5.7 sec

What is the power output of Audi S2 Sedan 1992 2.2i Turbo 20V (230 Hp) quattro?

230 Hp, 350 Nm
258 lb.-ft.

What is the engine displacement of Audi S2 Sedan 1992 2.2i Turbo 20V (230 Hp) quattro?

2.2 l
2226 cm³
135.84 cu. in.

What is the number of cylinders in 1992 Audi 2.2i Turbo 20V (230 Hp) quattro?

5, Inline

What is the drivetrain of Audi S2 Sedan 1992 2.2i Turbo 20V (230 Hp) quattro?

All wheel drive (4x4). Internal Combustion engine.

What is the length of 1992 Audi S2 Sedan?

4509 mm
177.52 in.

What is the width of 1992 Audi S2 Sedan?

1695 mm
66.73 in.

What is the kerb weight of 1992 Audi S2 2.2i Turbo 20V (230 Hp) quattro?

1520 kg
3351 lbs.

What is the maximum permissible mass of 1992 Audi S2 2.2i Turbo 20V (230 Hp) quattro?

1980 kg
4365 lbs.

What is the trunk (boot) capacity of 1992 Audi S2 Sedan?

430 - 712 l
15.2 - 25.1 cu. ft.

What are the number of gears and the gearbox type of 1992 Audi S2 2.2i Turbo 20V (230 Hp) quattro?

6, manual transmission

Audi
- Audi S2
  - S2
    - 2.2i Turbo 20V (230 Hp) quattro

Compare

General information

Brand

Audi

Model

Generation

Modification (Engine)

2.2i Turbo 20V (230 Hp) quattro

Start of production

October, 1992

End of production

December, 1995

Powertrain Architecture

Internal Combustion engine

Body type

Sedan

Seats

Doors

Looking for Audi S2 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

14 l/100 km 16.8 US mpg
20.2 UK mpg
7.1 km/l

Fuel consumption (economy) - extra urban

7.5 l/100 km 31.4 US mpg
37.7 UK mpg
13.3 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

6 sec

Acceleration 0 - 62 mph

6 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

5.7 sec

Maximum speed

246 km/h 153 mph

Weight-to-power ratio

6.6 kg/Hp, 151.3 Hp/tonne

Weight-to-torque ratio

4.3 kg/Nm, 230.3 Nm/tonne

Engine specs

Power

230 Hp @ 5900 rpm.

Power per litre

103.3 Hp/l

Torque

350 Nm @ 1950 rpm. 258 lb.-ft. @ 1950 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

ABY

Engine displacement

2226 cm³ 135.84 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

81 mm 3.19 in.

Piston Stroke

86.4 mm 3.4 in.

Compression ratio

9.3:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Turbocharger, Intercooler

Valvetrain

DOHC

Engine oil capacity

4.5 l 4.76 US qt | 3.96 UK qt

Engine oil specification

Coolant

8.5 l 8.98 US qt | 7.48 UK qt

Volume and weights

Kerb Weight

1520 kg 3351 lbs.

Max. weight

1980 kg 4365 lbs.

Max load

460 kg 1014 lbs.

Trunk (boot) space - minimum

430 l 15.2 cu. ft.

Trunk (boot) space - maximum

712 l 25.1 cu. ft.

Fuel tank capacity

64 l 16.91 US gal | 14.08 UK gal

Max. roof load

75 kg 165 lbs.

Permitted trailer load with brakes (8%)

1800 kg 3968 lbs.

Permitted trailer load with brakes (12%)

1700 kg 3748 lbs.

Permitted trailer load without brakes

640 kg 1411 lbs.

Permitted towbar download

50 kg 110 lbs.

Dimensions

Length

4509 mm 177.52 in.

Width

1695 mm 66.73 in.

Width including mirrors

1930 mm 75.98 in.

Height

1386 mm 54.57 in.

Wheelbase

2597 mm 102.24 in.

Front track

1448 mm 57.01 in.

Rear (Back) track

1474 mm 58.03 in.

Front overhang

963 mm 37.91 in.

Rear overhang

949 mm 37.36 in.

Ride height (ground clearance)

101 mm 3.98 in.

Minimum turning circle (turning diameter)

11.2 m 36.75 ft.

Drivetrain, brakes and suspension specs

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

6 gears, manual transmission

Front suspension

Independent, McPherson type

Rear suspension

Independent coil spring

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Hydraulic Steering

Tire size

205/55 R16

Wheel rim size

7J x 16

Specs of Audi S2 2.2i Turbo 20V (230 Hp) quattro /1992, 1993, 1994, 1995/
