Audi A4 Avant (B9 8W) 2.0 TFSI ultra (190 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Audi A4 Avant (B9 8W) 2.0 TFSI ultra (190 Hp) /Station wagon (estate) 2015 - 2018/

What is the body type of Audi A4 Avant (B9 8W)?

Station wagon (estate), 5 Doors, 5 Seats

What is the fuel consumption and economy of Audi A4 Avant (B9 8W) 2.0 TFSI ultra (190 Hp)?

5.6-6.1 l/100 km
42 - 38.6 US mpg
50.4 - 46.3 UK mpg
17.9 - 16.4 km/l

How environmentally friendly is Audi A4 2.0 TFSI ultra (190 Hp)?

127-139 g/km CO₂
Euro 6

How fast is 2015 A4 Avant (B9 8W) 2.0 TFSI ultra (190 Hp)?

236 km/h | 147 mph
0-100 km/h: 7.5 sec
0-60 mph: 7.1 sec

What is the power output of Audi A4 Station wagon (estate) 2015 2.0 TFSI ultra (190 Hp)?

190 Hp, 320 Nm
236 lb.-ft.

What is the engine displacement of Audi A4 Station wagon (estate) 2015 2.0 TFSI ultra (190 Hp)?

2.0 l
1984 cm³
121.07 cu. in.

What is the number of cylinders in 2015 Audi 2.0 TFSI ultra (190 Hp)?

4, Inline

What is the drivetrain of Audi A4 Avant (B9 8W) Station wagon (estate) 2015 2.0 TFSI ultra (190 Hp)?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2015 Audi A4 Station wagon (estate)?

4725 mm
186.02 in.

What is the width of 2015 Audi A4 Station wagon (estate)?

1842 mm
72.52 in.

What is the kerb weight of 2015 Audi A4 Avant (B9 8W) 2.0 TFSI ultra (190 Hp)?

1430 kg
3153 lbs.

What is the maximum permissible mass of 2015 Audi A4 Avant (B9 8W) 2.0 TFSI ultra (190 Hp)?

2035 kg
4486 lbs.

What is the trunk (boot) capacity of 2015 Audi A4 Station wagon (estate)?

505 - 1510 l
17.8 - 53.3 cu. ft.

What are the number of gears and the gearbox type of 2015 Audi A4 Avant (B9 8W) 2.0 TFSI ultra (190 Hp)?

6, manual transmission

Compare

General information

Brand

Audi

Model

Generation

A4 Avant (B9 8W)

Modification (Engine)

2.0 TFSI ultra (190 Hp)

Start of production

2015

End of production

2018

Powertrain Architecture

Internal Combustion engine

Body type

Station wagon (estate)

Seats

Doors

Looking for Audi A4 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

7.3-7.7 l/100 km 32.2 - 30.5 US mpg
38.7 - 36.7 UK mpg
13.7 - 13 km/l

Fuel consumption (economy) - extra urban

4.6-5.2 l/100 km 51.1 - 45.2 US mpg
61.4 - 54.3 UK mpg
21.7 - 19.2 km/l

Fuel consumption (economy) - combined

5.6-6.1 l/100 km 42 - 38.6 US mpg
50.4 - 46.3 UK mpg
17.9 - 16.4 km/l

CO₂ emissions

127-139 g/km

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

7.5 sec

Acceleration 0 - 62 mph

7.5 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

7.1 sec

Maximum speed

236 km/h 147 mph

Emission standard

Euro 6

Weight-to-power ratio

7.5 kg/Hp, 132.9 Hp/tonne

Weight-to-torque ratio

4.5 kg/Nm, 223.8 Nm/tonne

Engine specs

Power

190 Hp @ 4200-6000 rpm.

Power per litre

95.8 Hp/l

Torque

320 Nm @ 1450-4200 rpm. 236 lb.-ft. @ 1450-4200 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

EA888 / CVKB

Engine displacement

1984 cm³ 121.07 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

82.5 mm 3.25 in.

Piston Stroke

92.8 mm 3.65 in.

Compression ratio

11.65:1

Number of valves per cylinder

Fuel injection system

Direct injection and Multi-port manifold injection

Engine aspiration

Turbocharger, Intercooler

Valvetrain

DOHC

Engine oil capacity

5.2 l 5.49 US qt | 4.58 UK qt

Engine oil specification

Coolant

7.8 l 8.24 US qt | 6.86 UK qt

Engine systems

Start & Stop System

Volume and weights

Kerb Weight

1430 kg 3153 lbs.

Max. weight

2035 kg 4486 lbs.

Max load

605 kg 1334 lbs.

Trunk (boot) space - minimum

505 l 17.8 cu. ft.

Trunk (boot) space - maximum

1510 l 53.3 cu. ft.

Fuel tank capacity

54 l 14.27 US gal | 11.88 UK gal

Max. roof load

90 kg 198 lbs.

Permitted trailer load with brakes (8%)

1700 kg 3748 lbs.

Permitted trailer load with brakes (12%)

1500 kg 3307 lbs.

Permitted trailer load without brakes

750 kg 1653 lbs.

Permitted towbar download

80 kg 176 lbs.

Dimensions

Length

4725 mm 186.02 in.

Width

1842 mm 72.52 in.

Width including mirrors

2022 mm 79.61 in.

Height

1434 mm 56.46 in.

Wheelbase

2820 mm 111.02 in.

Front track

1572 mm 61.89 in.

Rear (Back) track

1555 mm 61.22 in.

Front overhang

880 mm 34.65 in.

Rear overhang

1025 mm 40.35 in.

Drag coefficient (C_d)

0.29

Minimum turning circle (turning diameter)

11.6 m 38.06 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

6 gears, manual transmission

Front suspension

Independent multi-link suspension, Anti-roll bar

Rear suspension

Independent multi-link spring suspension with anti-roll bar

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

225/50 R17; 245/40 R18; 245/35 R19

Wheel rim size

7.5J x 17; 8J x 18; 8.5J x 19

Specs of Audi A4 Avant (B9 8W) 2.0 TFSI ultra (190 Hp) /2015, 2016, 2017, 2018/
