Aixam SANSATION BREAK GT 0.6d (15 Hp) VSD | Technical specs, data, fuel consumption, Dimensions

Key specs

Aixam SANSATION BREAK GT 0.6d (15 Hp) VSD /Hatchback 2016 - 2020/

What is the body type of Aixam SANSATION BREAK?

Hatchback, 3 Doors, 4 Seats

What is the fuel consumption and economy of Aixam SANSATION BREAK GT 0.6d (15 Hp) VSD?

3.6 l/100 km
65.3 US mpg
78.5 UK mpg
27.8 km/l

How environmentally friendly is Aixam SENSATION GT 0.6d (15 Hp) VSD?

95 g/km CO₂

How fast is 2016 SANSATION BREAK GT 0.6d (15 Hp) VSD?

87 km/h | 54 mph

What is the power output of Aixam SENSATION Hatchback 2016 GT 0.6d (15 Hp) VSD?

15 Hp, 33 Nm
24 lb.-ft.

What is the engine displacement of Aixam SENSATION Hatchback 2016 GT 0.6d (15 Hp) VSD?

0.6 l
599 cm³
36.55 cu. in.

What is the number of cylinders in 2016 Aixam GT 0.6d (15 Hp) VSD?

2, Inline

What is the drivetrain of Aixam SANSATION BREAK Hatchback 2016 GT 0.6d (15 Hp) VSD?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2016 Aixam SENSATION Hatchback?

3000 mm
118.11 in.

What is the width of 2016 Aixam SENSATION Hatchback?

1500 mm
59.06 in.

What is the kerb weight of 2016 Aixam SANSATION BREAK GT 0.6d (15 Hp) VSD?

450 kg
992 lbs.

What is the maximum permissible mass of 2016 Aixam SANSATION BREAK GT 0.6d (15 Hp) VSD?

760 kg
1676 lbs.

What are the number of gears and the gearbox type of 2016 Aixam SANSATION BREAK GT 0.6d (15 Hp) VSD?

1, automatic transmission VSD

Aixam
- Aixam SENSATION
  - SANSATION BREAK
    - GT 0.6d (15 Hp) VSD
    - 0.5d (8 Hp) Automatic

Compare

General information

Brand

Aixam

Model

SENSATION

Generation

SANSATION BREAK

Modification (Engine)

GT 0.6d (15 Hp) VSD

Start of production

2016

End of production

2020

Powertrain Architecture

Internal Combustion engine

Body type

Hatchback

Seats

Doors

Looking for Aixam SENSATION on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - combined

3.6 l/100 km 65.3 US mpg
78.5 UK mpg
27.8 km/l

CO₂ emissions

95 g/km

Fuel Type

Diesel

Maximum speed

87 km/h 54 mph

Weight-to-power ratio

30 kg/Hp, 33.3 Hp/tonne

Weight-to-torque ratio

13.6 kg/Nm, 73.3 Nm/tonne

Engine specs

Power

15 Hp @ 3600 rpm.

Power per litre

25 Hp/l

Torque

33 Nm @ 2500 rpm. 24 lb.-ft. @ 2500 rpm.

Maximum engine speed

3600 rpm.

Engine layout

Front, Transverse

Engine Model/Code

KUBOTA Z602

Engine displacement

599 cm³ 36.55 cu. in.

Number of cylinders

Engine configuration

Inline

Fuel injection system

Precombustion chamber injection

Engine aspiration

Naturally aspirated engine

Engine oil capacity

2.3 l 2.43 US qt | 2.02 UK qt

Engine oil specification

Coolant

2 l 2.11 US qt | 1.76 UK qt

Volume and weights

Kerb Weight

450 kg 992 lbs.

Max. weight

760 kg 1676 lbs.

Max load

310 kg 683 lbs.

Fuel tank capacity

16 l 4.23 US gal | 3.52 UK gal

Dimensions

Length

3000 mm 118.11 in.

Width

1500 mm 59.06 in.

Wheelbase

2000 mm 78.74 in.

Front track

1345 mm 52.95 in.

Rear (Back) track

1345 mm 52.95 in.

Minimum turning circle (turning diameter)

4 m 13.12 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

1 gears, automatic transmission VSD

Front suspension

Independent, McPherson type

Rear suspension

Independent coil spring

Front brakes

Disc

Rear brakes

Drum

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Tire size

155/70 R14

Wheel rim size

Specs of Aixam SANSATION BREAK GT 0.6d (15 Hp) VSD /2016, 2017, 2018, 2019, 2020/
