Aion ES 55.2 kWh (136 Hp) | Technical specs, data, battery, electric range, Dimensions

Key specs

Aion ES 55.2 kWh (136 Hp) /Sedan 2023 - /

What is the body type of Aion ES?

Sedan, 4 Doors, 5 Seats

What is the all-electric range of 55.2 kWh (136 Hp)?

364 km
226 mi

What is the electricity consumption of Aion ES 55.2 kWh (136 Hp)?

16.7 kWh/100 km
26.88 kWh/100 mi
125 MPGe
6 km/kWh
3.7 mi/kWh

How fast is 2023 ES 55.2 kWh (136 Hp)?

150 km/h | 93 mph
0-100 km/h: 12.1 sec
0-60 mph: 11.5 sec

What is the power output of Aion ES Sedan 2023 55.2 kWh (136 Hp)?

136 Hp, 225 Nm
166 lb.-ft.

What is the drivetrain of Aion ES Sedan 2023 55.2 kWh (136 Hp)?

Front wheel drive. BEV (Electric Vehicle). One electric motor drives the front wheels.

What is the length of 2023 Aion ES Sedan?

4810 mm
189.37 in.

What is the width of 2023 Aion ES Sedan?

1880 mm
74.02 in.

What is the kerb weight of 2023 Aion ES 55.2 kWh (136 Hp)?

1645-1665 kg
3627 - 3671 lbs.

What is the maximum permissible mass of 2023 Aion ES 55.2 kWh (136 Hp)?

2135 kg
4707 lbs.

What is the trunk (boot) capacity of 2023 Aion ES Sedan?

450 l
15.9 cu. ft.

What is the number of gears in What is the gearbox type of 2023 Aion ES 55.2 kWh (136 Hp)?

1, automatic transmission

Aion
- Aion ES
  - ES
    - 55.2 kWh (136 Hp)

Compare

General information

Brand

Aion

Model

Generation

Modification (Engine)

55.2 kWh (136 Hp)

Start of production

November, 2023 year

Powertrain Architecture

BEV (Electric Vehicle)

Body type

Sedan

Seats

Doors

Looking for Aion ES on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Acceleration 0 - 100 km/h

12.1 sec

Acceleration 0 - 62 mph

12.1 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

11.5 sec

Maximum speed

150 km/h 93 mph

Weight-to-power ratio

12.1 kg/Hp, 82.7 Hp/tonne

Weight-to-torque ratio

7.3 kg/Nm, 136.8 Nm/tonne

Electric cars and hybrids specs

Gross battery capacity

55.2 kWh

Battery voltage

326.4 V

Battery technology

Lithium iron phosphate (LiFePO₄)

Battery location

Below the floor

Electric range (WLTP)

364 km 226 mi

Electric range (CLTC)

442 km 275 mi

Average Energy consumption (WLTP)

16.7 kWh/100 km 26.88 kWh/100 mi
125 MPGe
6 km/kWh
3.7 mi/kWh

Average Energy consumption (CLTC)

13.6 kWh/100 km 21.89 kWh/100 mi
154 MPGe
7.4 km/kWh
4.6 mi/kWh

Charging ports

Electric motor 1

Electric motor power

136 Hp

Electric motor Torque

225 Nm 166 lb.-ft.

Electric motor model/code

TZ184XYA2002

Maximum revolutions of the electric motor

14000 rpm.

Electric motor location

Front axle, Transverse

Electric motor type

Synchronous

System power

136 Hp

System torque

225 Nm 166 lb.-ft.

Volume and weights

Kerb Weight

1645-1665 kg 3627 - 3671 lbs.

Max. weight

2135 kg 4707 lbs.

Max load

470-490 kg 1036 - 1080 lbs.

Trunk (boot) space - minimum

450 l 15.9 cu. ft.

Dimensions

Length

4810 mm 189.37 in.

Width

1880 mm 74.02 in.

Height

1545 mm 60.83 in.

Wheelbase

2750 mm 108.27 in.

Front track

1600 mm 62.99 in.

Rear (Back) track

1602 mm 63.07 in.

Front overhang

960 mm 37.8 in.

Rear overhang

1100 mm 43.31 in.

Ride height (ground clearance)

120 mm 4.72 in.

Minimum turning circle (turning diameter)

11 m 36.09 ft.

Approach angle

13°

Departure angle

14°

Climb angle

16.7°

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the front wheels.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Semi-independent, coil spring, Torsion bar

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

215/55 R17

Wheel rims size

Specs of Aion ES 55.2 kWh (136 Hp) /2023, 2024, 2025, 2026/
