Acura Integra III Sedan 1.8 (196 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Acura Integra III Sedan 1.8 (196 Hp) /Sedan 1994 - 2001/

What is the body type of Acura Integra III Sedan?

Sedan, 4 Doors, 5 Seats

How fast is 1994 Integra III Sedan 1.8 (196 Hp)?

234 km/h | 145 mph
0-100 km/h: 6.7 sec
0-60 mph: 6.4 sec

What is the power output of Acura Integra Sedan 1994 1.8 (196 Hp)?

196 Hp, 178 Nm
131 lb.-ft.

What is the engine displacement of Acura Integra Sedan 1994 1.8 (196 Hp)?

1.8 l
1797 cm³
109.66 cu. in.

What is the number of cylinders in 1994 Acura 1.8 (196 Hp)?

4, Inline

What is the drivetrain of Acura Integra III Sedan Sedan 1994 1.8 (196 Hp)?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 1994 Acura Integra Sedan?

4525 mm
178.15 in.

What is the width of 1994 Acura Integra Sedan?

1710 mm
67.32 in.

What is the kerb weight of 1994 Acura Integra III Sedan 1.8 (196 Hp)?

1120 kg
2469 lbs.

What is the maximum permissible mass of 1994 Acura Integra III Sedan 1.8 (196 Hp)?

1550 kg
3417 lbs.

What is the trunk (boot) capacity of 1994 Acura Integra Sedan?

311 l
11 cu. ft.

What are the number of gears and the gearbox type of 1994 Acura Integra III Sedan 1.8 (196 Hp)?

5, manual transmission

Acura
- Acura Integra
  - Integra III Sedan
    - 1.8 (196 Hp)
    - 1.8 (170 Hp)
    - 1.8 (141 Hp) Automatic
    - 1.8 (141 Hp)

Compare

General information

Brand

Acura

Model

Integra

Generation

Integra III Sedan

Modification (Engine)

1.8 (196 Hp)

Start of production

1994

End of production

2001

Powertrain Architecture

Internal Combustion engine

Body type

Sedan

Seats

Doors

Looking for Acura Integra on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

9.7 l/100 km 24.2 US mpg
29.1 UK mpg
10.3 km/l

Fuel consumption (economy) - extra urban

7.8 l/100 km 30.2 US mpg
36.2 UK mpg
12.8 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

6.7 sec

Acceleration 0 - 62 mph

6.7 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

6.4 sec

Maximum speed

234 km/h 145 mph

Weight-to-power ratio

5.7 kg/Hp, 175 Hp/tonne

Weight-to-torque ratio

6.3 kg/Nm, 158.9 Nm/tonne

Engine specs

Power

196 Hp @ 8000 rpm.

Power per litre

109.1 Hp/l

Torque

178 Nm @ 7300 rpm. 131 lb.-ft. @ 7300 rpm.

Maximum engine speed

8400 rpm.

Engine layout

Front, Transverse

Engine Model/Code

B18C1

Engine displacement

1797 cm³ 109.66 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

81 mm 3.19 in.

Piston Stroke

87.2 mm 3.43 in.

Compression ratio

10.6:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

4.8 l 5.07 US qt | 4.22 UK qt

Engine oil specification

Coolant

6.7 l 7.08 US qt | 5.9 UK qt

Volume and weights

Kerb Weight

1120 kg 2469 lbs.

Max. weight

1550 kg 3417 lbs.

Max load

430 kg 948 lbs.

Trunk (boot) space - minimum

311 l 11 cu. ft.

Fuel tank capacity

50 l 13.21 US gal | 11 UK gal

Dimensions

Length

4525 mm 178.15 in.

Width

1710 mm 67.32 in.

Height

1370 mm 53.94 in.

Wheelbase

2620 mm 103.15 in.

Front track

1476 mm 58.11 in.

Rear (Back) track

1468 mm 57.8 in.

Ride height (ground clearance)

150 mm 5.91 in.

Drag coefficient (C_d)

0.34

Minimum turning circle (turning diameter)

10.8 m 35.43 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Independent coil spring

Rear suspension

Independent coil spring

Front brakes

Ventilated discs

Rear brakes

Disc

Tire size

195/55 R15; 195/60 R16; 215/45 R16

Wheel rim size

15; 16

Specs of Acura Integra III Sedan 1.8 (196 Hp) /1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001/
