Abarth 500C 1.4 T-Jet (135 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Abarth 500C 1.4 T-Jet (135 Hp) /Cabriolet 2012 - 2014/

What is the body type of Abarth 500C?

Cabriolet, 2 Doors, 4 Seats

What is the fuel consumption and economy of Abarth 500C 1.4 T-Jet (135 Hp)?

6.5 l/100 km
36.2 US mpg
43.5 UK mpg
15.4 km/l

How environmentally friendly is Abarth 500 1.4 T-Jet (135 Hp)?

155 g/km CO₂
Euro 5

How fast is 2012 500C 1.4 T-Jet (135 Hp)?

205 km/h | 127 mph
0-100 km/h: 7.9 sec
0-60 mph: 7.5 sec

What is the power output of Abarth 500 Cabriolet 2012 1.4 T-Jet (135 Hp)?

135 Hp, 206 Nm
152 lb.-ft.

What is the engine displacement of Abarth 500 Cabriolet 2012 1.4 T-Jet (135 Hp)?

1.4 l
1368 cm³
83.48 cu. in.

What is the number of cylinders in 2012 Abarth 1.4 T-Jet (135 Hp)?

4, Inline

What is the drivetrain of Abarth 500C Cabriolet 2012 1.4 T-Jet (135 Hp)?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2012 Abarth 500 Cabriolet?

3657 mm
143.98 in.

What is the width of 2012 Abarth 500 Cabriolet?

1627 mm
64.06 in.

What is the kerb weight of 2012 Abarth 500C 1.4 T-Jet (135 Hp)?

1075 kg
2370 lbs.

What is the maximum permissible mass of 2012 Abarth 500C 1.4 T-Jet (135 Hp)?

1430 kg
3153 lbs.

What is the trunk (boot) capacity of 2012 Abarth 500 Cabriolet?

182 - 520 l
6.4 - 18.4 cu. ft.

What are the number of gears and the gearbox type of 2012 Abarth 500C 1.4 T-Jet (135 Hp)?

5, manual transmission

Abarth
- Abarth 500
  - 500C
    - 1.4 T-Jet (140 Hp) MTA
    - 1.4 T-Jet (135 Hp)

Compare

General information

Brand

Abarth

Model

500

Generation

500C

Modification (Engine)

1.4 T-Jet (135 Hp)

Start of production

2012

End of production

2014

Powertrain Architecture

Internal Combustion engine

Body type

Cabriolet

Seats

Doors

Looking for Abarth 500 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban (NEDC)

8.5 l/100 km 27.7 US mpg
33.2 UK mpg
11.8 km/l

Fuel consumption (economy) - extra urban (NEDC)

5.4 l/100 km 43.6 US mpg
52.3 UK mpg
18.5 km/l

Fuel consumption (economy) - combined (NEDC)

6.5 l/100 km 36.2 US mpg
43.5 UK mpg
15.4 km/l

CO₂ emissions (NEDC)

155 g/km

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

7.9 sec

Acceleration 0 - 62 mph

7.9 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

7.5 sec

Maximum speed

205 km/h 127 mph

Emission standard

Euro 5

Weight-to-power ratio

8 kg/Hp, 125.6 Hp/tonne

Weight-to-torque ratio

5.2 kg/Nm, 191.6 Nm/tonne

Engine specs

Power

135 Hp @ 5500 rpm.

Power per litre

98.7 Hp/l

Torque

206 Nm @ 3000 rpm. 152 lb.-ft. @ 3000 rpm.

Engine layout

Front, Transverse

Engine Model/Code

312A1000

Engine displacement

1368 cm³ 83.48 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

72 mm 2.83 in.

Piston Stroke

84 mm 3.31 in.

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Turbocharger, Intercooler

Valvetrain

DOHC

Engine oil capacity

2.9 l 3.06 US qt | 2.55 UK qt

Engine oil specification

Coolant

5.2 l 5.49 US qt | 4.58 UK qt

Volume and weights

Kerb Weight

1075 kg 2370 lbs.

Max. weight

1430 kg 3153 lbs.

Max load

355 kg 783 lbs.

Trunk (boot) space - minimum

182 l 6.4 cu. ft.

Trunk (boot) space - maximum

520 l 18.4 cu. ft.

Fuel tank capacity

35 l 9.25 US gal | 7.7 UK gal

Dimensions

Length

3657 mm 143.98 in.

Width

1627 mm 64.06 in.

Width including mirrors

1893 mm 74.53 in.

Height

1488 mm 58.58 in.

Wheelbase

2300 mm 90.55 in.

Front track

1409 mm 55.47 in.

Rear (Back) track

1402 mm 55.2 in.

Front overhang

776 mm 30.55 in.

Rear overhang

581 mm 22.87 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Independent, McPherson type, Anti-roll bar

Rear suspension

Anti-roll bar, Elastic beam

Front brakes

Ventilated discs, 284x22 mm

Rear brakes

Disc, 240x11 mm

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

195/45 R16

Wheel rim size

6.5J x 16

Specs of Abarth 500C 1.4 T-Jet (135 Hp) /2012, 2013, 2014/
