1996 Citroen ZX (N2, Phase II) 5-door 1.8 i 16V (110 Hp)

1995 Citroen ZX (N2, Phase II) 5-door - Photo 1
Citroen ZX (N2, Phase II) 5-door - Photo 2Citroen ZX (N2, Phase II) 5-door - Photo 3Citroen ZX (N2, Phase II) 5-door - Photo 4Citroen ZX (N2, Phase II) 5-door - Photo 5Citroen ZX (N2, Phase II) 5-door - Photo 6Citroen ZX (N2, Phase II) 5-door - Photo 7Citroen ZX (N2, Phase II) 5-door - Photo 8

Key specs

Citroen ZX Hatchback 1996, 1997

What is the body type, Citroen ZX (N2, Phase II) 5-door?Hatchback, 5 Doors, 5 Seats
How much power, Citroen ZX Hatchback 1996 1.8 i 16V (110 Hp)?110 Hp, 158 Nm
116.53 lb.-ft.
What is the engine size, Citroen ZX Hatchback 1996 1.8 i 16V (110 Hp)?1.8 l
1761 cm3
107.46 cu. in.
How many cylinders, 1996 Citroen 1.8 i 16V (110 Hp)?4, Inline
What is the drivetrain, Citroen ZX (N2, Phase II) 5-door Hatchback 1996 1.8 i 16V (110 Hp)?Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.
How long is this vehicle, 1996 Citroen ZX Hatchback?4071 mm
160.28 in.
How wide is the vehicle, 1996 Citroen ZX Hatchback?1688 mm
66.46 in.
How much trunk (boot) space, 1996 Citroen ZX Hatchback?324 - 926 l
11.44 - 32.7 cu. ft.
How many gears, What type is the gearbox, 1996 Citroen ZX (N2, Phase II) 5-door 1.8 i 16V (110 Hp)?5, manual transmission

Citroen ZX (N2, Phase II) 5-door 1.8 i 16V (110 Hp) 1996, 1997 Specs

General information
BrandCitroen
Model ZX
Generation ZX (N2, Phase II) 5-door
Modification (Engine) 1.8 i 16V (110 Hp)
Start of production 1996 year
End of production 1997 year
Powertrain Architecture Internal Combustion engine
Body typeHatchback
Seats 5
Doors 5
Performance specs
Fuel Type Petrol (Gasoline)
Engine specs
Power 110 Hp @ 5500 rpm.
Power per litre 62.5 Hp/l
Torque 158 Nm @ 4250 rpm. 116.53 lb.-ft. @ 4250 rpm.
Engine layout Front, Transverse
Engine Model/Code LFY XU7JP4
Engine displacement 1761 cm3 107.46 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 83 mm 3.27 in.
Piston Stroke 81.4 mm 3.2 in.
Compression ratio 10.4
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 4.25 l 4.49 US qt | 3.74 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8 l 8.45 US qt | 7.04 UK qt
Space, Volume and weights
Trunk (boot) space - minimum 324 l 11.44 cu. ft.
Trunk (boot) space - maximum 926 l 32.7 cu. ft.
Fuel tank capacity 54 l 14.27 US gal | 11.88 UK gal
Dimensions
Length 4071 mm 160.28 in.
Width 1688 mm 66.46 in.
Height 1399 mm 55.08 in.
Wheelbase 2540 mm 100 in.
Front track 1422 mm 55.98 in.
Rear (Back) track 1415 mm 55.71 in.
Front overhang 849 mm 33.43 in.
Rear overhang 682 mm 26.85 in.
Minimum turning circle (turning diameter) 11.1 m 36.42 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent type McPherson, Wishbone
Rear suspension Hydro-pneumatic element, Trailing arm
Front brakesVentilated discs
Rear brakesDrum
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 185/60 R14
Wheel rims size5.5J x 14
